LCD Screen Display Panel

HSD058BHW1-P00 5.9 inch 720*1512 LCD Screen Display

All Category

Floor Standing Digital Signage

HSD058BHW1-P00 5.9 inch 720*1512 LCD Screen Display

Brand Name:	HannStar
Model Number:	HSD058BHW1-P00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

HSD058BHW1-P00

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Q-CUT (Full Cell)

Resolution:

720(RGB)×1512 286PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

63.936(W)×134.266(H) Mm

Designed For:

Handheld & PDA

Display Colors:

16.7M 70%NTSC

Supply Ability:

100000 Unit/Units per Month

Product Description

HSD058BHW1-P00 5.9 inch 720*1512 LCD Screen Display

HSD058BHW1-P00 LCD Panel Product details :

Brand	HannStar
Model P/N	HSD058BHW1-P00
Diagonal Size	5.9"
Panel Type	a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution	720(RGB)×1512 286PPI
Pixel Format	RGB Vertical Stripe
Active Area	63.936(W)×134.266(H) mm
Bezel Opening	-
Outline Size	65.936(W)×140.156(H)×0.8(D) mm
Brightness	0 cd/m²
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Best View on	Symmetry
Glass Depth	0.40+0.40 mm
Display Colors	16.7M 70%NTSC
Frequency	-
Weight	-
Surface	Without Polarizer
Contrast Ratio	1000:1 (Typ.) (TM)
Display Mode	IPS Pro, Normally Black, Transmissive
Response Time	25 (Typ.)(Tr+Td)
Transmissivity	3.2% (Typ.)(with Polarizer)
Lamp Type	No B/L
Touch Screen	Without
Application	Handheld & PDA
Driver IC	COGSuggest HX8394F, JD9365D, ILI9881A, OTM1290A
Environment	Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C

HSD058BHW1-P00 LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

HSD058BHW1-P00 LCD Panel Shipping and Package :

HSD058BHW1-P00 LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

HSD058BHW1-P00 LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

HSD058BHW1-P00 LCD Panel FAQ :

Q: Can you give me a discount if I need a large quantity of HSD058BHW1-P00 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can You declare my order of HSD058BHW1-P00 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How to make payment of HSD058BHW1-P00 ?

A: We accept T/T , Paypal , western union .

Q: How long is the warranty ?

A: We offer 90 days warranty .
