AV101HDT-A10-28PE 10.1 inch 1280*720 LCD Screen Display

Brand Name:	BOE
Model Number:	AV101HDT-A10-28PE
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

AV101HDT-A10-28PE

Diagonal Size:

10.1"

Panel Type:

A-Si TFT-LCD, Assembly

Resolution:

1280(RGB)×720, WXGA 145PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

223.68(W)×125.82(H) Mm

Designed For:

Outdoor High Brightness ，Automotive Display

Support Color:

16.7M 72% NTSC

Contrast Ratio:

1000:1 (Typ.) (TM)

View Direction:

Symmetry

Supply Ability:

100000 Unit/Units per Month

Product Description

AV101HDT-A10-28PE 10.1 inch 1280*720 LCD Screen Display

AV101HDT-A10-28PE LCD Panel Product details :

Brand	BOE
Model P/N	AV101HDT-A10-28PE
Diagonal Size	10.1"
Panel Type	a-Si TFT-LCD, Assembly
Resolution	1280(RGB)×720, WXGA 145PPI
Pixel Format	RGB Vertical Stripe
Active Area	223.68(W)×125.82(H) mm
Bezel Opening	-
Outline Dim.	247.86(W)×160.65(H) ×11.49(D) mm
Treatment	Hard coating
Luminance	700 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Max.)(Tr+Td)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Operating Mode	-
Support Color	16.7M 72% NTSC
Light Source	9S3P WLED , Without Driver
Weight	-
Designed For	Outdoor High Brightness ,Automotive Display
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (1 ch, 8-bit) , 60 pins Connector
Power Supply	3.3V (Typ.)
Environment	Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C

AV101HDT-A10-28PE LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

AV101HDT-A10-28PE LCD Panel Shipping and Package :

AV101HDT-A10-28PE LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

AV101HDT-A10-28PE LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

AV101HDT-A10-28PE LCD Panel FAQ :

Q: How to make payment of AV101HDT-A10-28PE ?

A: We accept T/T , Paypal , western union .

Q: Can You declare my order of AV101HDT-A10-28PE to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can I pay my order of AV101HDT-A10-28PE via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: If I place order now,when will you ship the goods of AV101HDT-A10-28PE ?

A: The order will be shipped within 2-3 working days after received your payment.
