LX057A1BB01 5.7 inch 1080*1920 LCD Screen LCD Display

Brand Name:	Sharp
Model Number:	LX057A1BB01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LX057A1BB01

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Full Cell

Resolution:

1080(RGB)×1920, FHD 386PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

70.956(W)×126.144(H) Mm

Designed For:

Mobile Phone

Frequency:

Light Source:

No B/L

Support Color:

81%NTSC

Supply Ability:

100000 Unit/Units per Month

Product Description

LX057A1BB01 5.7 inch 1080*1920 LCD Screen LCD Display

LX057A1BB01 LCD Panel Product details :

Brand	Sharp
Model P/N	LX057A1BB01
Diagonal Size	5.7"
Panel Type	a-Si TFT-LCD, CELL, Full Cell
Resolution	1080(RGB)×1920, FHD 386PPI
Pixel Format	RGB Vertical Stripe
Active Area	70.956(W)×126.144(H) mm
Bezel Opening	-
Outline Dim.	72.96(W)×132.6(H)×0.3(D) mm
Treatment	With Polarizer
Luminance	0 cd/m²
Contrast Ratio	1500:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	-
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Operating Mode	New Mode2, Normally Black, Transmissive
Plate Thickness	0.15+0.15 mm
Transmittance	3.8% (Typ.)(with Polarizer)
Support Color	81%NTSC
Light Source	No B/L
Weight	7.20g (Typ.)
Designed For	Mobile Phone
Frame Rate	60Hz
Touch Panel	Without
D-IC Detail	COG Suggest NT35695, R63315, R63422
Environment	Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C
Original CELL LCD Screen LX057A1BB01 5.7 inch LCD Display Module

LX057A1BB01 LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

LX057A1BB01 LCD Panel Shipping and Package :

LX057A1BB01 LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

LX057A1BB01 LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

LX057A1BB01 LCD Panel FAQ :

Q: Can You declare my order of LX057A1BB01 at a very low value ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty of LX057A1BB01 ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of LX057A1BB01 ?

A: Of course!If you make a large order, we will give you a discount.

Q: If I order LX057A1BB01 now,when will you ship the goods ?

A: The order will be shipped within 2-3 working days after received your payment.
