LM270WF5-SSA1 27.0 inch 1080p LCD display IPS screen

Brand Name:	LG Display
Model Number:	LM270WF5-SSA1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LM270WF5-SSA1

Diagonal Size:

27.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 81PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

597.888(W)×336.312(H) Mm

Designed For:

Desktop Monitor

Lamp Type:

WLED [14S4P] , 30K Hours , W/O Driver

Interface Type:

LVDS (2 Ch, 8-bit)30 Pins Connector

Power Supply:

5.0V (Typ.)

Supply Ability:

100000 Unit/Units per Month

Product Description

LM270WF5-SSA1 27.0 inch 1080p LCD display IPS screen

LM270WF5-SSA1 LCD Panel Product details :

Brand	LG Display
Model P/N	LM270WF5-SSA1
Diagonal Size	27.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 81PPI
Pixel Format	RGB Vertical Stripe
Active Area	597.888(W)×336.312(H) mm
Bezel Opening	-
Outline Dim.	617.1(W)×361.3(H)×14.75(D) mm
Luminance	250 cd/m² (Typ.)
View Direction	Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Support Color	16.7M 72% NTSC
Weight	3.30/3.50Kgs (Typ./Max.)
Frame Rate	60Hz
Treatment	Antiglare (Haze 25%)
Contrast Ratio	1000:1 (Typ.) (TM)
Response Time	14 (Typ.)(G to G)
Operating Mode	IPS, Normally Black, Transmissive
Light Source	WLED [14S4P] , 30K hours , W/O Driver
Designed For	Desktop Monitor
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit)30 pins Connector
Power Supply	5.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C

LM270WF5-SSA1 LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

LM270WF5-SSA1 LCD Panel Shipping and Package :

LM270WF5-SSA1 LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

LM270WF5-SSA1 LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

LM270WF5-SSA1 LCD Panel FAQ :

Q: If I place order now,when will you ship the goods LM270WF5-SSA1 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity LM270WF5-SSA1 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How long will I receive my goods LM270WF5-SSA1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: How to make payment LM270WF5-SSA1 ?

A: We accept T/T , Paypal , western union .
