TM062FYMC01 6.2 inch 1080*2246 LCD Screen Display For Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM062FYMC01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM062FYMC01 | Diagonal Size: | 6.2" |
|---|---|---|---|
| Panel Type: | LTPS TFT-LCD, CELL, Full Cell | Resolution: | 1080(RGB)×2246 403PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.04(W)×141.498(H) Mm |
| Application: | Mobile Phone | Luminance: | 0 (cd/m²) |
| Good View At: | Symmetry | Treatment: | Without Polarizer |
Product Description
TM062FYMC01 6.2 inch 1080*2246 LCD Screen Display For Phone
TM062FYMC01 LCD Panel Product details :
| Brand | TIANMA |
| Model P/N | TM062FYMC01 |
| Diagonal Size | 6.2" |
| Panel Type | LTPS TFT-LCD, CELL, Full Cell |
| Resolution | 1080(RGB)×2246 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×141.498(H) mm |
| Bezel Opening | - |
| Outline(mm) | 69.44(W)×145.798(H)×0.28(D) |
| Luminance | 0 (cd/m²) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Glass Thickness | 0.14+0.14 mm |
| Color Depth | 16.7M 83% NTSC |
| Mass | TBD |
| Refresh Rate | - |
| Treatment | Without Polarizer |
| Contrast Ratio | 1500 : 1 (Typ.) (TM) |
| Work Mode | SFT, Normally Black, Transmissive |
| Response | 35 (Max.)(Tr+Td) ms |
| Transmissivity | - |
| Backlight | No B/L |
| Used for | Mobile Phone |
| Touchscreen | Without |
| Driver IC list | SuggestCOGFT8719 |
| Voltage Supply | 1.8/5.5/-5.5V (Typ.)(IOICC/AVDD/AVEE) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
TM062FYMC01 LCD Panel Shipping and Package :
At our company, we take the safety and security of your shipment seriously. Our team's top priority is to ensure that your parcel arrives at its destination in pristine condition. To achieve this, we take extra care in packing your items securely before shipping them out.
We understand that no one wants to receive a damaged package, which is why we use the highest quality materials and techniques to protect your products during transportation. Whether you're sending fragile glassware, electronics or any other valuable item, our packaging process is designed to prevent any harm or mishap along the way.
We always keep an eye on the latest trends and advancements in packaging technology to ensure that we are up to date with the latest tools and techniques that can help us make your delivery experience seamless and hassle-free. You can trust us to take the utmost care in handling and shipping your items, and we will do everything we can to exceed your expectations.
So if you want to ship your products with confidence, then look no further than our company. We believe in providing our customers with the best possible service, and that includes ensuring their parcels are safe and secure throughout the journey. You can rely on us for quality packaging and delivery services that are second to none.
Warranty for 1 year.
After the initial 30 day refund guarantee, it is your responsibility to return the item to us.
All faults, except for physical damage, liquid damage, and battery failure, are covered by the warranty.
Q: Can you tested the TM062FYMC01 before shipping ?
A: Of course , our lcd panel TM062FYMC01 was Strictly tested before shipping.
Q: How to order TM062FYMC01 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel TM062FYMC01 received can't work ?
A:TM062FYMC01 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
