TM055JVZG08 5.5 inch 720*1280 LCD Screen Display For Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM055JVZG08 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM055JVZG08 | Diagonal Size: | 5.5" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, Assembly | Resolution: | 720(RGB)×1280, WXGA 268PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.04(W)×120.96(H) Mm |
| Application: | Mobile Phone、Handheld & PDA | Luminance: | 350 Cd/m² (Typ.) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Touchscreen: | PCAP, I²C |
Product Description
TM055JVZG08 5.5 inch 720*1280 LCD Screen Display For Phone
TM055JVZG08 LCD Panel Product details :
| Brand | TIANMA |
| Model P/N | TM055JVZG08 |
| Diagonal Size | 5.5" |
| Panel Type | a-Si TFT-LCD, Assembly |
| Resolution | 720(RGB)×1280, WXGA 268PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline(mm) | 76 × 143.4× 4.03 (H×V×D) |
| Treatment | Hard coating |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 12/12 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | - |
| Color Depth | 16.7M 70%NTSC |
| Backlight | 6S2PWLED, 20K hours, No Driver |
| Mass | - |
| Used for | Mobile Phone,Handheld & PDA |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP, I²C |
| Signal Type | MIPI (4 data lanes), 31 pins FPC |
| Voltage Supply | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
TM055JVZG08 LCD Panel Specification :
Quality Assurance:
Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.
TM055JVZG08 LCD Panel Shipping and Package :
TM055JVZG08 LCD Panel Shipping Information :
Standard Shipping Practices:
We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.
Processing Time:
We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.
Contact Information Requirement:
To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.
Attention – Expedited Shipping Options:
For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.
TM055JVZG08 LCD Panel Receiving goods :
1. Regular cleaning: For electronic products, dust and dirt are the biggest killers. Regular cleaning of screens, keyboards, sockets, and other areas can prevent damage caused by these fine particles.
2. Avoid heavy object pressure: For mobile devices and computers, avoid placing heavier objects on them, especially the computer screen and keyboard. The pressure of heavy objects can cause damage and malfunction of the screen and keyboard.
3. Prevent overcharging: For electronic products, overcharging can seriously damage the battery and charger. When the battery is fully charged, unplug the power cord of the charger in a timely manner to avoid damage caused by overcharging.
4. Pay attention to storage environment: For some sensitive electronic products, such as mobile phones and tablets, avoid storing them in damp, high or low temperature environments. These environments can affect the lifespan of electronic components and batteries in electronic products.
In short, proper use and maintenance of products can extend their service life, reduce unnecessary damage and malfunctions. We should actively face the problems in life and create a good living environment for ourselves and others as much as possible.
TM055JVZG08 LCD Panel FAQ :
Q: How long will I receive my goods TM055JVZG08 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of TM055JVZG08 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of TM055JVZG08 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90days warranty .
Want to Know more details about this product
