C060SWA3-3 6.0 inch 720*1280 LCD Screen Display For Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | IVO |
| Model Number: | C060SWA3-3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | C060SWA3-3 | Diagonal Size: | 6.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1280, WXGA 247PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 73.98(W)×131.52(H) Mm |
| Application: | Mobile Phone | Refresh Rate: | 60Hz |
| Lamp Type: | No B/L | Environment: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
Product Description
C060SWA3-3 6.0 inch 720*1280 LCD Screen Display For Phone
C060SWA3-3 LCD Panel Product details :
| Brand | IVO |
| Model P/N | C060SWA3-3 |
| Diagonal Size | 6.0" |
| Panel Type | a-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1280, WXGA 247PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 73.98(W)×131.52(H) mm |
| Bezel Opening | - |
| Outline Size | 76.38(W)×139.02(H)×0.4(D) mm |
| Surface | Without Polarizer |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 4.0% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 70%NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COG Suggest ILI9881C |
| Panel Weight | 21.1g (Typ.) |
| Application | Mobile Phone |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Small 6.0 inch LCD Screen C060SWA3-3 TFT LCD Panel for Phone | |
C060SWA3-3 LCD Panel Shipping and Package :
Returns and exchanges are common things for consumers during the shopping process. Although we strive to ensure the quality of the products and the accuracy of the delivery process, in rare cases, there may still be situations where the products are incompatible or damaged. We are very sorry for any inconvenience caused to you in this situation.
However, please note that during the return and exchange process, if it is due to the consumer's own mistake in ordering or incompatible products, the return postage will be borne by the consumer. Therefore, we suggest carefully checking the product information before shopping, confirming your own needs before placing an order, to avoid unnecessary losses.
If you receive a faulty item, please contact us promptly and we will arrange for replacement as soon as possible. We will adhere to the service philosophy of "customer first", provide you with the highest quality service, and ensure your consumption experience.
Finally, we hope that consumers can actively address issues during the return and exchange process, and believe that through communication and cooperation between both parties, the problem can be best resolved. Thank you for your understanding and support of our work!
We need to start from the customer's needs. Customer needs are the starting point and foothold of our services. Only by deeply understanding customer needs can we provide truly valuable services to them. Therefore, we need to understand customer needs through various channels and means, including market research, customer feedback, data analysis, and so on. Based on understanding customer needs, we can develop corresponding service plans and strategies to provide customers with personalized, differentiated, and diversified services.
Q: Can you tested the C060SWA3-3 before shipping ?
A: Of course , our lcd panel C060SWA3-3 was Strictly tested before shipping.
Q: How to order C060SWA3-3 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel C060SWA3-3 received can't work ?
A:C060SWA3-3 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
