LCD Touch Panel Display

LX063A1BB02 6.3 inch 1080*2340 LCD Display Panel with touch Screen

All Category

Floor Standing Digital Signage

LX063A1BB02 6.3 inch 1080*2340 LCD Display Panel with touch Screen

Brand Name:	Sharp
Model Number:	LX063A1BB02
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LX063A1BB02

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Q-CUT (Full Cell)

Resolution:

1080(RGB)×2340 409PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

67.068(W)×145.314(H) Mm

Outline (mm):

68.468×149.36×0.3 (H×V×D)

Treatment:

Without Polarizer

Contrast Ratio:

1500 : 1 (Typ.) (TM)

Application:

Mobile Phone

Supply Ability:

100000 Unit/Units per Month

Product Description

LX063A1BB02 6.3 inch 1080*2340 LCD Display Panel with touch Screen

LX063A1BB02 LCD Panel Product details :

Brand	Sharp
Model P/N	LX063A1BB02
Diagonal Size	6.3"
Panel Type	a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution	1080(RGB)×2340 409PPI
Pixel Format	RGB Vertical Stripe
Active Area	67.068(W)×145.314(H) mm
Bezel Opening	-
Outline (mm)	68.468×149.36×0.3 (H×V×D)
Treatment	Without Polarizer
Luminance	0 cd/m²
Contrast Ratio	1500 : 1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Response	30 (Typ.)(Tr+Td) ms
Good View at	Symmetry
Work Mode	New Mode2, Normally Black, Transmissive
Glass Thickness	0.15+0.15 mm
Transmissivity	3.33% (Typ.)
Color Depth	16.7M 83%NTSC
Backlight	No B/L
Mass	7.90g (Typ.)
Used for	Mobile Phone
Refresh Rate	-
Touchscreen	In-Cell Touch
Driver IC list	Suggest COG NT33672A
Max. Ratings	Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
LX063A1BB02 6.3 inch RGB 1080*2340 Touch LCD Display Screen

LX063A1BB02 LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

LX063A1BB02 LCD Panel Shipping and Package :

LX063A1BB02 LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

LX063A1BB02 LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

LX063A1BB02 LCD Panel FAQ :

Q: How to order LX063A1BB02 ?

A: We accept T/T , PAYPAL , WESTERN UNION .

Q: What happen if the lcd pane LX063A1BB02 I received can't work ?

A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.

Q: When will my order lcd panel LX063A1BB02 ship?

A: The order are shipped within 1-2 working days after received the payment.

Q: Can you declared low value of my order about LX063A1BB02 ?

A: Yes , we can . But you need to leave message to us before shipping.
