LCD Screen Display Panel

LTM230HU03 23.0 inch TFT-LCD Screen Panel Display

All Category

Floor Standing Digital Signage

LTM230HU03 23.0 inch TFT-LCD Screen Panel Display

Brand Name:	Samsung
Model Number:	LTM230HU03
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LTM230HU03

Diagonal Size:

23.0"

Resolution:

1920(RGB)×1080, FHD 95PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

509.76(W)×286.74(H) Mm

Bezel Opening:

513.6(W)×290.6(H) Mm

Outline(mm):

523.2 × 300.8× 13 (H×V×D)

Treatment:

Hard Coating (3H), Reflection 4.0% (Typ.)

Luminance:

250 Cd/m² (Typ.)

Used For:

Desktop Monitor、Gaming

Supply Ability:

100000 Unit/Units per Month

Product Description

LTM230HU03 23.0 inch TFT-LCD Screen Panel Display

LTM230HU03 LCD Panel Product details :

Brand	Samsung
Model P/N	LTM230HU03
Diagonal Size	23.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 95PPI
Pixel Format	RGB Vertical Stripe
Active Area	509.76(W)×286.74(H) mm
Bezel Opening	513.6(W)×290.6(H) mm
Outline(mm)	523.2 × 300.8× 13 (H×V×D)
Treatment	Hard coating (3H), Reflection 4.0% (Typ.)
Luminance	250 cd/m² (Typ.)
Contrast Ratio	1000 : 1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Response	3 (Typ.)(Tr+Td) ms
Good View at	-
Work Mode	TN, Normally White, Transmissive
Color Depth	16.7M 72%NTSC
Backlight	6 stringsWLED, 30K hours, No Driver
Mass	1.65Kgs (Max.)
Used for	Desktop Monitor,Gaming
Refresh Rate	120Hz
Touchscreen	Without
Signal Type	LVDS (4 ch, 8-bit), 82 pinsConnector
Voltage Supply	5.0V (Typ.)
Max. Ratings	Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C

LTM230HU03 LCD Panel Specification :

Quality Assurance:

Before dispatching any of our LCD panels, we conduct a thorough quality check and testing process. This rigorous evaluation ensures that every unit meets our high standards for functionality and performance. Our commitment to quality means that you receive a product that is ready for immediate use, providing reliable and consistent performance. This process is part of our dedication to delivering excellence and customer satisfaction with every LCD panel purchased.

LTM230HU03 LCD Panel Shipping and Package :

LTM230HU03 LCD Panel Shipping Information :

Standard Shipping Practices:

We adhere to high standards in shipping practices, ensuring that your goods are transported safely and efficiently.

Processing Time:

We strive to dispatch your purchase within 3 working days after confirming receipt of payment. This quick turnaround ensures that your LCD panel reaches you in a timely manner.

Contact Information Requirement:

To facilitate on-time delivery, please provide a valid phone number when placing your order. This allows the delivery service to contact you directly in case of any delivery-related updates or issues.

Attention – Expedited Shipping Options:

For those requiring faster delivery, we offer expedited shipping options. Please contact us prior to placing your order if you wish to utilize expedited shipping via DHL or US Federal Express. We can then provide you with additional details on the costs and delivery timeframes associated with these services.

LTM230HU03 LCD Panel Return Policy :

Please be aware that tampering with or opening our product voids any eligibility for return or refund unless authorized by us. If any concerns arise regarding the product, kindly reach out to us for assistance. Unauthorized alterations or opening of our products will render them ineligible for refund.

In the event that your purchase does not meet your expectations, we offer a 14-day window for exchanges or refunds from the date of purchase. To proceed with either an exchange or refund, we require the original receipt, and the product must be in its original condition, which includes the intact box, packaging, and all accompanying accessories. Please allow a maximum of 10 business days for the return processing to be completed.

Please note that shipping and handling charges are non-refundable. You are responsible for covering the shipping costs for returns. Once the returned item reaches our warehouse, we will initiate a full refund for your purchase.

LTM230HU03 LCD Panel FAQ :

Q: Do you accept sample orders of LTM230HU03 ?

A: Of course! Sample order is welcome.

Q: Can I pay my order of LTM230HU03 vai credit card ?

A: Yes! You can use your credit card through your Paypal account.

Q: How long is the warranty ?

A: We offer 90 days warranty.

Q: If I place order now, when will you ship the goods of LTM230HU03 ?

A: The order will be shipped within 2-3 working days after received your payment.
