LTM11C307L 11.3 inch 1024*768 TFT LCD Screen Display
Product Details:
Place of Origin: | China |
Brand Name: | TOSHIBA |
Model Number: | LTM11C307L |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LTM11C307L | Diagonal Size: | 11.3" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1024(RGB)×768, XGA 112PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 230.4(W)×172.8(H) Mm |
Designed For: | Laptop | Frame Rate: | 60Hz |
Product Description
LTM11C307L 11.3 inch 1024*768 TFT LCD Screen Display
LTM11C307L LCD Panel Product details :
Brand | TOSHIBA |
Model P/N | LTM11C307L |
Diagonal Size | 11.3" |
Panel Type | LTPS TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 112PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 230.4(W)×172.8(H) mm |
Bezel Opening | - |
Viewing Angle | - |
Display Mode | TN, Normally White, Transmissive |
Best View on | - |
Response Time | - |
Display Colors | 262K |
Lamp Type | |
Frequency | 60Hz |
Touch Screen | - |
Shape Style | - |
Application | Laptop |
Signal Interface | LVDS (1 ch, 6-bit), 14 pins Connector |
LTM11C307L 11.3 inch 1024*768 TFT LCD Screen Display |
LTM11C307L LCD Panel Shipping and Package :
LTM11C307L LCD Panel FAQ :
Q: What happen if the lcd panel LTM11C307L I received can't work ?
A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
Q:Can you declared low value for my order when shipping?
A:Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
