LTM10C209F 10.4 inch 640*480 TFT-LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | TOSHIBA |
| Model Number: | LTM10C209F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTM10C209F | Diagonal Size: | 10.4" |
|---|---|---|---|
| Panel Type: | LTPS TFT-LCD, LCM | Resolution: | 640(RGB)×480, VGA 76PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 211.2(W)×158.4(H) Mm |
| Application: | Industrial | Backlight: | 2 PcsCCFL |
| Highlight: | 640*480 TFT-LCD Screen Display,10.4 inch TFT-LCD Screen Display,LTM10C209F |
||
Product Description
LTM10C209F 10.4 inch 640*480 TFT-LCD Screen Display
LTM10C209F LCD Panel Product details :
| Brand | TOSHIBA |
| Model P/N | LTM10C209F |
| Diagonal Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA 76PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 211.2(W)×158.4(H) mm |
| Bezel Opening | - |
| Outline Size | 265(W)×188.8(H) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | 262K |
| Weight | - |
| Surface | - |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 50/50 (Max.)(Tr/Td) |
| Lamp Type | 2 pcs CCFL |
| Application | Industrial |
| Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
| LTM10C209F 10.4 inch 640*480 TFT-LCD Screen Display | |
LTM10C209F LCD Screen Payment and Taxation:
We offer a variety of convenient payment methods to facilitate your purchase, including PayPal, ALI Sinosure orders, bank transfers, and more.
Please note that products shipped outside of China may be subject to import tariffs, taxes, and fees imposed by the destination country's customs authorities. These additional costs are not included in the price or shipping cost of the product and are solely the responsibility of the consignee.
In the event that an order is not confirmed in a timely manner, it will be automatically cancelled after 7 working days. We encourage prompt confirmation to ensure smooth processing of your order.
LTM10C209F LCD Panel Shipping and Package :
LTM10C209F LCD Screen Item Not Received:
At our end, we meticulously handle all orders in strict accordance with our commitments. However, it's imperative to note that once the package leaves our facility, its transit is entrusted to third-party courier services. If, due to unforeseen circumstances such as delays stemming from the courier's operational constraints, issues with international or local postal services, or thorough inspections by international customs authorities, your item experiences a delay, we regret to inform you that we cannot be held liable for such delays. Please rest assured that we are committed to assisting you to the best of our abilities within the confines of our control.
LTM10C209F LCD Screen Warranty / Returns:
At our establishment, we prioritize your satisfaction and offer a 30-day peace of mind guarantee, allowing for either a refund or exchange should any concerns arise.
In the unfortunate event of receiving a defective or damaged item during transit, we kindly request that you report it to us within 48 hours of receipt.
To initiate a return or exchange, simply ensure that the purchased item(s) are returned within 30 days of receipt, maintaining its original (re-sellable) condition and packaging. Please note that refunds will be issued minus the cost of Postage & Packaging.
Should you encounter any faulty or incorrect item(s), it is imperative to return them within 30 days of receipt. The cost of return postage rests upon the customer, and we advise obtaining proof of postage in the rare event of non-receipt.
Most of our items come with a three-month warranty, covering manufacturing defects exclusively. This warranty does not extend to damage or mishandling caused by the user.
In the event that an item supplied by us develops a fault due to a manufacturing defect, we encourage you to reach out to us via the eBay messaging system for RMA (return merchandise authorization) and further return instructions. Please ensure that the returned item is accompanied by the RMA number, a copy of the invoice, and a clear statement outlining the reason for return.
Please note that refunds or replacements will only be processed upon receipt of the returned item. All returns are diligently processed within 5 working days of receipt at our office.
LTM10C209F LCD Panel FAQ :
Q: When will my order LTM10C209F ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: What happen if the lcd panel LTM10C209F I received can't work ?
A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: Are you manufactory or trade company?
A: Shenzhen YONG SHENG INNOVATIVE TECHNOLOGY Co, Ltd is a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q:Can you declared low value for my order when shipping?
A:Yes, We can do it for you if you need.
Want to Know more details about this product
