LTD141ECEP 14.0 inch LVDS 262K TFT-LCD Screen Display
Product Details:
Place of Origin: | China |
Brand Name: | Toshiba Matsushita |
Model Number: | LTD141ECEP |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LTD141ECEP | Diagonal Size: | 14.0" |
---|---|---|---|
Panel Type: | LTPS TFT-LCD, LCM | Resolution: | 1024(RGB)×768, XGA 91PPI |
Active Area: | 285.696(W)×214.272(H) Mm | Display Colors: | 262K |
Designed For: | Laptop | Frame Rate: | 60Hz |
Mode: | TN, Normally White, Transmissive | Signal Type: | LVDS (1 Ch, 6-bit), 20 PinsConnector |
Product Description
LTD141ECEP 14.0 inch LVDS 262K TFT-LCD Screen Display
LTD141ECEP LCD Panel Product details :
Brand | TOSHIBA |
Model P/N | LTD141ECEP |
Diagonal Size | 14.0" |
Panel Type | LTPS TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 91PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 285.696(W)×214.272(H) mm |
Bezel Opening | 288.7(W)×217.3(H) mm |
Outline Dim. | 298.5(W)×226.5(H)×6(D) mm |
Treatment | - |
Luminance | 200 cd/m² (Typ.) |
Contrast Ratio | 200:1 (Typ.) (TM) |
View Direction | 6 o'clock |
Response Time | 50/50 (Max.)(Tr/Td) |
Viewing Angle | - |
Operating Mode | TN, Normally White, Transmissive |
Support Color | 262K |
Light Source | CCFL [1 pcs], W/O Driver |
Form Style | Wedge (PCBA Bent, T≥5.2mm) |
Designed For | Laptop |
Frame Rate | 60Hz |
Touch Panel | Without |
Interface Type | LVDS (1 ch, 6-bit), 20 pinsConnector |
Power Supply | 3.3V (Typ.) |
Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
LTD141ECEP 14.0 inch LVDS 262K TFT-LCD Screen Display |
LTD141ECEP LCD Panel Shipping and Package :
LTD141ECEP LCD Panel FAQ :
Q: Can You declare my order of LTD141ECEP at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: Do you accept sample orders for LTD141ECEP ?
A: Of course!sample order is welcome !
Q: How to make payment for LTD141ECEP ?
A: We accept T/T , Paypal , western union .
Q: How long will I receive my goods of LTD141ECEP ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
