LCD Laptop Screen
>
B120XAB01.0 12.0 inch lcd screen for Slim Laptop original

B120XAB01.0 12.0 inch lcd screen for Slim Laptop original

Brand Name: AUO
Model Number: B120XAB01.0
MOQ: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Model P/N:
B120XAB01.0
Diagonal Size:
12.0"
Panel Type:
A-Si TFT-LCD, Assembly
Resolution:
1366(RGB)×912 136PPI
Pixel Format:
RGB Vertical Stripe
Active Area:
253.46(W)×169.22(H) Mm
Display Colors:
262K 50%NTSC
Lamp Type:
WLED, 15K Hours, With LED Driver
Application:
Laptop
Frequency:
60Hz
Supply Ability:
100000 Unit/Units per Month
Product Description

B120XAB01.0 12.0 inch lcd screen for Slim Laptop original


B120XAB01.0 Product details :



Brand AUO
Model P/N B120XAB01.0
Diagonal Size 12.0"
Panel Type a-Si TFT-LCD, Assembly
Resolution 1366(RGB)×912 136PPI
Pixel Format RGB Vertical Stripe
Active Area 253.46(W)×169.22(H) mm
Bezel Opening -
Outline Dim. 283.74(H)×211.44(V)×4.07(D) mm
Treatment Anti-Scatter, Hard coating (3H)
Luminance 235 cd/m² (Typ.)
Contrast Ratio 800:1 (Typ.) (TM)
View Direction Symmetry
Response Time 25 (Typ.)(Tr/Td)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10)
Operating Mode AHVA, Normally Black, Transmissive
Support Color 262K 50%NTSC
Light Source WLED, 15K hours, With LED Driver
Form Style Slim (PCBA Flat, T≤3.2mm)
Designed For Laptop
Frame Rate 60Hz
Touch Panel On-Cell Touch, I²C
Interface Type eDP (1 Lane), eDP1.2, 40 pinsConnector
Power Supply 3.3V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C


B120XAB01.0 Important:

Specific laptop models can come in many sizes and resolutions. Laptop LCD resolution should not beupgraded or downgraded. You must
confirm that this screen matches your laptop in size and in resolution before you purchase! No Returns Due To Improper Installation or Incompatibility.

B120XAB01.0 Payment and Taxes:

1. We recommend Alipay to be safer.

2. Shipment of the products outside China will incur import duties and other charges which are not included in the price or freight of the products and are for the responsibility of the recipient.

B120XAB01.0 About transportation:


1: The recipient must be the company's full name or full name.

2: If the product ordered is very expensive, you need to get the packaging quickly. It is recommended to use DHL or EMS for transportation.

3: If you choose DHL shipping. Some DHL remote addresses require an additional remote address service fee, approximately $ 35. In some countries, aircraft cannot carry spare batteries. Some motherboards do not have a BIOS battery. You can use the original BIOS battery. I hope you can understand.

4: If a customs clearance fee is incurred, the buyer bears it.

5: After receiving the package, please check the package in time. If the packaging is damaged, save the video evidence. We can ask the logistics company to make up.

B120XAB01.0 Return:

Customer has 7 days to inspect/install the product upon delivery. Please report any damage or dead-on-arrial (DOA) during the period.

Customer may exchange for same exact product within 90-day, when it is determined defects. When exchanging for a different product, customer is considered to conduct two separate transactions, a return and a purchase.

B120XAB01.0 FAQ:



Q: Can You declare my order of B120XAB01.0 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .



Q: Can you give me a discount if I need a large quantity of B120XAB01.0 ?

A: Of course!If you make a large order, we will give you a discount.



Q: Do you accept sample orders of B120XAB01.0 ?

A: Of course!sample order is welcome !



Q: Can I pay my order of B120XAB01.0 via credit card ?

A: Yes!you can use your credit card through your Paypal account.


B120XAB01.0 Shipping and Package :
B120XAB01.0 12.0 inch lcd screen for Slim Laptop original 0
