LTD104XA1F 10.4 inch 1024*768 lcd Screen display panel
Product Details:
Place of Origin: | China |
Brand Name: | Toshiba Matsushita |
Model Number: | LTD104XA1F |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LTD104XA1F | Diagonal Size: | 10.4" |
---|---|---|---|
Resolution: | 1024(RGB)×768, XGA 123PPI | Pixel Format: | RGB Vertical Stripe |
Active Area: | 211.2(W)×158.4(H) Mm | Panel Type: | LTPS TFT-LCD, LCM |
Display Mode: | TN, Normally White, Transmissive | Application: | Laptop |
Product Description
LTD104XA1F 10.4 inch 1024*768 lcd Screen display panel
LTD104XA1F LCD Panel Product details :
Brand | TOSHIBA |
Model P/N | LTD104XA1F |
Diagonal Size | 10.4" |
Panel Type | LTPS TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 123PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 211.2(W)×158.4(H) mm |
Bezel Opening | 217.2(W)×164.7(H) mm |
Outline(mm) | 238.6 × 186.4× 5.2 (H×V×D) |
Treatment | - |
Luminance | 300 cd/m² (Typ.) |
Contrast Ratio | 300 : 1 (Typ.) (TM) |
Viewing Angle | - |
Response | 50/50 (Typ.)(Tr/Td) ms |
Good View at | - |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 262K |
Backlight | WLED, 45K hours, No Driver |
Outline Shape | - |
Used for | Laptop |
Refresh Rate | 60Hz |
Touchscreen | Without |
Signal Type | LVDS (1 ch, 6-bit), 14 pinsConnector |
Voltage Supply | 3.3V (Typ.) |
Max. Ratings | - Operating Temp.: -20 ~ 60 °C |
LTD104XA1F 10.4 inch 1024*768 lcd Screen display panel |
LTD104XA1F LCD Panel Shipping and Package :
LTD104XA1F LCD Panel FAQ :
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of LTD104XA1F ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty of LTD104XA1F ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of LTD104XA1F ?
A: Of course!If you make a large order, we will give you a discount.
