LTA150B850F 15.0 inch 400 cd/m2 lcd display panel LCD Module
Product Details:
Place of Origin: | China |
Brand Name: | Toshiba Matsushita |
Model Number: | LTA150B850F |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LTA150B850F | Diagonal Size: | 15.0" |
---|---|---|---|
Resolution: | 1024(RGB)×768, XGA 85PPI | Pixel Format: | RGB Vertical Stripe |
Active Area: | 304.128(W)×228.096(H) Mm | Luminance: | 400 Cd/m² (Typ.) |
Contrast Ratio: | 700 : 1 (Typ.) (TM) | Work Mode: | TN, Normally White, Transmissive |
Signal Type: | LVDS (1 Ch, 8-bit), 20 Pins Connector |
Product Description
LTA150B850F 15.0 inch 400 cd/m2 lcd display panel LCD Module
LTA150B850F LCD Panel Product details :
Brand | Toshiba Matsushita |
Model P/N | LTA150B850F |
Diagonal Size | 15.0" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 85PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 304.128(W)×228.096(H) mm |
Bezel Opening | - |
Outline(mm) | 351 × 254.7× 21.5 (H×V×D) |
Treatment | - |
Luminance | 400 cd/m² (Typ.) |
Contrast Ratio | 700 : 1 (Typ.) (TM) |
Viewing Angle | 80/80/60/60 (Typ.)(CR≥10) |
Response | 16 (Typ.)(Tr+Td) ms |
Good View at | - |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 16.2M |
Backlight | 4 pcsCCFL, 30K hours, No Driver |
Mass | 1.35Kgs |
Used for | |
Refresh Rate | 60Hz |
Touchscreen | Without |
Signal Type | LVDS (1 ch, 8-bit), 20 pins Connector |
Voltage Supply | 3.3V (Typ.) |
Max. Ratings | Storage Temp.: -20 ~ 80 °C Operating Temp.: -10 ~ 70 °C |
LTA150B850F 15.0 inch 400 cd/m2 lcd display panel LCD Module |
LTA150B850F LCD Panel Shipping and Package :
LTA150B850F LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of LTA150B850F ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders of LTA150B850F ?
A: Of course!sample order is welcome !
Q: Can I pay my order of LTA150B850F via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How can I trace my order of LTA150B850F ?
A: we will give you tracking number then you can trace your order from website.
