F060A18-6T1 6.0 inch 720*1440 LCD Screen panel LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | F060A18-6T1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | F060A18-6T1 | Diagonal Size: | 6.0" |
|---|---|---|---|
| Resolution: | 720(RGB)×1440 268PPI | Pixel Format: | RGB Vertical Stripe |
| Operating Mode: | AAS, Normally Black, Transmissive | Support Color: | 16.7M 69%NTSC |
| Designed For: | Mobile Phone | Environment: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Touchscreen: | In-Cell Touch | Backlight: | No B/L |
Product Description
F060A18-6T1 6.0 inch 720*1440 LCD Screen panel LCD Display
F060A18-6T1 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | F060A18-6T1 |
| Diagonal Size | 6.0" |
| Panel Type | a-Si TFT-LCD, CELL |
| Resolution | 720(RGB)×1440 268PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.4(W)×136.09(H) mm |
| Bezel Opening | - |
| Outline Size | 70.04(W)×141.88(H)×0.4(D) mm |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 35 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Glass Thickness | 0.20+0.20 mm |
| Transmissivity | 3.74% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 69%NTSC |
| Backlight | No B/L |
| Mass | - |
| Used for | Mobile Phone |
| Refresh Rate | - |
| Touchscreen | In-Cell Touch |
| Driver IC list | Suggest COG NT36525, FT8006U, HX83102B |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
Feature Regarding F060A18-6T1 LCD Screen:
-The new 6.0 inch F060A18-6T1 LCD display comes with a one-year warranty. If you need more quantity, please contact me.
-The quality of the product is perfect. They undergo testing before being sent.
-These projects are consistent with the image and title description.
-The item is in good condition and will undergo testing to ensure quality before shipment.
-If you have any questions about this product, please contact me before placing an order. I will reply to you as soon as possible.
-The item is wrapped in bubble wrap and then placed in a box, which provides strong screen protection. So, please don't worry.
F060A18-6T1 LCD Panel Shipping and Package :
Shipping Details for F060A18-6T1 LCD Screen:
Rest assured, your item is in excellent condition and will be carefully prepared for shipping.
All orders will be dispatched to the buyer's specified shipping address as listed during the purchase process. If you wish to have your order delivered to an alternative address, kindly ensure that you update your shipping details accordingly before completing your transaction.
Please note that the seller reserves the right to opt for a shipping company other than the one initially indicated in the listing, at their discretion. Common carriers utilized include USPS, UPS, and FedEx. Should you prefer to use your own shipping label, please feel free to get in touch with us.
Upon shipment, all packages will be provided with a tracking number for your convenience. We extend our shipping services internationally; however, please be advised that the buyer assumes responsibility for all associated international shipping and handling fees.
While we prioritize shipping the model specified in the title, in the event that this model is unavailable, we will promptly dispatch its compatible universal counterpart to fulfill your order.
F060A18-6T1 LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of F060A18-6T1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of F060A18-6T1 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my order of F060A18-6T1 ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty .
