F060A18HD4-6T1 6.0 inch LCD Screen panel For Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | F060A18HD4-6T1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | F060A18HD4-6T1 | Diagonal Size: | 6.0" |
|---|---|---|---|
| Resolution: | 720(RGB)×1440 268PPI | Pixel Format: | RGB Vertical Stripe |
| Operating Mode: | AAS, Normally Black, Transmissive | Support Color: | 16.7M 69%NTSC |
| Designed For: | Mobile Phone | D-IC Detail: | COG Suggest NT36525, FT8006U, HX83102B |
| Touch Panel: | In-Cell Touch | Environment: | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Product Description
F060A18HD4-6T1 6.0 inch LCD Screen panel For Mobile Phone
F060A18HD4-6T1 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | F060A18HD4-6T1 |
| Diagonal Size | 6.0" |
| Panel Type | a-Si TFT-LCD, CELL |
| Resolution | 720(RGB)×1440 268PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.4(W)×136.09(H) mm |
| Bezel Opening | - |
| Outline Dim. | 70.04(H)×141.88(V)×0.4(D) mm |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Plate Thickness | 0.20+0.20 mm |
| Transmittance | 3.74% (Typ.)(with Polarizer) |
| Support Color | 16.7M 69%NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | In-Cell Touch |
| D-IC Detail | COG Suggest NT36525, FT8006U, HX83102B |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Important Note Regarding F060A18HD4-6T1 LCD Screen:
The part numbers mentioned in the titles serve solely as a reference to aid you in locating a compatible screen for your existing model number. Please be aware that receiving the exact part number as listed in the title is not guaranteed. Instead, we will dispatch a 100% compatible item that matches the specifications of the original part number. It's common for manufacturers to alter part numbers over time, rendering certain numbers obsolete. Furthermore, the images included in the listing are intended for illustrative purposes only, showcasing the connector's position and the fixing points.
F060A18HD4-6T1 LCD Panel Shipping and Package :
RETURN POLICY for F060A18HD4-6T1 LCD Screen:
Any issue to return, You can return it to us within 30 Days receipt of your item,
Before returning, please contact us immediately via message
so that Our customer service team will gladly contact you for further arrangement upon your request.
Refund is applicable according to below condition 1,2
1. In case of below conditions,
In refunding, shipping cost will be deducted.
1) ALL accessories must be unused; ALL accessory packages must be unopened.
2) ALL items must be intact and undamaged (except for defects in manufacturing).
3) Items must be in good conditions with all original accessories, manuals, and packing materials.
2. In case of below conditions,
In refunding, an restock fee of the item price plus shipping cost will be deducted
1) Some accessories were used; ALL accessories in the package were be opened.
2) Some items were damaged (except for defects in manufacturing).
-Any missing parts or damaged items will result in rejection on the return.
In case of any defectives found, only defects in manufacturing are accepted as the reason of return.
-After We receive the return product, Refund will be done.
F060A18HD4-6T1 LCD Panel FAQ :
Q: Can you test the lcd panel F060A18HD4-6T1 before shipping ?
A: Yes , of course , don't worry , our item was tested ok before shipping .
Q: Do you accept the sample order F060A18HD4-6T1 ?
A: Yes , sample order is welcome.
Q: Can you declared low value of my order F060A18HD4-6T1 ?
A: Yes , we can , you can tell us before shipping .
Q: How long the warranty of lcd F060A18HD4-6T1 ?
A: 90 days .
Contact for F060A18HD4-6T1 LCD Screen:
At our establishment, we prioritize our reputation, recognizing the significance of trust in online transactions. Should you find yourself dissatisfied with your order, we encourage you to reach out to us, and we will diligently collaborate with you to address any concerns until they are resolved to your contentment. Please anticipate a response to all inquiries within 1-3 days, as we strive to provide timely assistance and support to our valued customers.
