B101AW06 V4 10.1 inch LVDS 1024*600 LCD Screen Panel

Brand Name:	AUO
Model Number:	B101AW06 V4
MOQ:	1pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

B101AW06 V4

Diagonal Size:

10.1"

Resolution:

1024(RGB)×600, WSVGA 117PPI

Brightness:

200 Cd/m² (Typ.)

Contrast Ratio:

400:1 (Typ.) (TM)

Response Time:

30 (Typ.)(Tr+Td)

Designed For:

Netbook PC

Input Voltage:

3.3V (Typ.)

Supply Ability:

100000 Unit/Units per Month

Product Description

B101AW06 V4 10.1 inch LVDS 1024*600 LCD Screen Panel

B101AW06 V4 LCD Panel Product details :

Brand	AUO
Model P/N	B101AW06 V4
Diagonal Size	10.1"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)×600, WSVGA 117PPI
Pixel Format	RGB Vertical Stripe
Active Area	222.72(W)×125.28(H) mm
Bezel Opening	225.72(W)×128.28(H) mm
Outline Dim.	243(W)×146.5(H)×3.6(D) mm
Luminance	200 cd/m² (Typ.)
View Direction	6 o'clock
Viewing Angle	45/45/15/35 (Typ.)(CR≥10)
Support Color	262K 45% NTSC
Form Style	Flat (PCBA Flat, T3.4~4.0mm)
Frame Rate	60Hz
Treatment	Antiglare
Contrast Ratio	400:1 (Typ.) (TM)
Response Time	9/7 (Typ.)(Tr/Td)
Operating Mode	TN, Normally White, Transmissive
Light Source	WLED , With LED Driver
Designed For	Netbook PC
Touch Panel	Without
Interface Type	LVDS (1 ch, 6-bit)40 pins Connector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
B101AW06 V4 10.1 inch LVDS 1024*600 LCD Screen Panel

B101AW06 V4 LCD Display - Extremely Important Information:

Matching Specifications: It is crucial to match the resolution, backlight, and screen size of the replacement screen with your current screen. Any deviation from your current screen specifications may result in incompatibility with your system.

Contact for Assistance: If you are unsure about the specifications of your current screen, please don't hesitate to contact us. Our team will gladly assist you in determining the correct specifications to ensure compatibility with your system.

100% Compatibility Guarantee: Rest assured, you will receive a replacement screen that is 100% compatible with your system. However, please note that the exact brand and part number of the screen you receive may vary based on market availability. Regardless, the replacement screen will meet the necessary specifications for seamless integration with your device.

For further inquiries or assistance regarding screen compatibility, please reach out to our customer support team. We are committed to ensuring that you receive the correct replacement screen for your needs.

B101AW06 V4 LCD Panel Shipping and Package :

B101AW06 V4 10.1 inch LVDS 1024*600 LCD Screen Panel 0

B101AW06 V4 LCD Display SHIPPING :

We use ALI stander shipping EMS DHL fedex and so on. you can choose when you place order .

The items will be sent within 1-2 business days after payment is completed.(some products need more days accounding to the stock )

Each order will be attached a tracking number and we will send to you.

B101AW06 V4 LCD Display Warranty:

Warranty Duration: The warranty period is guaranteed for 3 months from the date of purchase.

Product Replacement: In the event of receiving counterfeit or fake products, we offer a replacement with new and genuine items.

However, it is imperative to ensure that the returned product is unused and free from any man-made damages.

Return Shipping Conditions: Customers are required to ship the product back to us using appropriate packaging to prevent any damages during the return transit.

Quality Assurance: Rest assured, each product undergoes thorough testing before shipment. We ensure that every unit is in optimal working condition, with a 100% guarantee of functionality prior to dispatch.

B101AW06 V4 LCD Panel FAQ :

Q: When will my order B101AW06 V4 ship?

A: The order are shipped within 1-2 working days after received the payment.

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.

Q: How long will I receive my goods of lcd B101AW06 V4 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
