LB070W02-TMJ2 Original 7.0 inch 480*234 LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | LG |
| Model Number: | LB070W02-TMJ2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LB070W02-TMJ2 | Resolution: | 480(RGB)×234 76PPI |
|---|---|---|---|
| Pixel Format: | RGB Vertical Stripe | Active Area: | 154.08(W)×86.58(H) Mm |
| Outline(mm): | 164.9(W)×100(H)×6(D) Mm | Luminance: | 220 Cd/m² (Typ.) |
| Viewing Angle: | 65/65/45/55 (Typ.)(CR≥10) | Signal Type: | TFT Specific Analog RGB, 26 Pins FPC |
Product Description
LB070W02-TMJ2 Original 7.0 inch 480*234 LCD Screen Display
LB070W02-TMJ2 LCD Panel Product details :
| Brand | LG |
| Model P/N | LB070W02-TMJ2 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 480(RGB)×234 76PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 154.08(W)×86.58(H) mm |
| Bezel Opening | 156.2(W)×88.8(H) mm |
| Outline Size | 164.9(W)×100(H)×6(D) mm |
| Surface | Antiglare |
| Brightness | 220 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Viewing Angle | 65/65/45/55 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Display Colors | Full color |
| Lamp Type | 1 pcsCCFL, 20K hours, Without Driver |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | 170g (Typ.) |
| Application | Digital Photo Frame,Portable DVD Player,Video Door Phone |
| Signal Interface | TFT Specific Analog RGB, 26 pins FPC |
| Input Voltage | 3.3/5.0/16.5/-10V (Typ.)(VDD1/VDD2/VGH/VGL) |
| Environment | Operating Temp.: -10 ~ 60 °C ;Storage Temp.: -20 ~ 70 °C |
| LB070W02-TMJ2 Original 7.0 inch 480*234 LCD Screen Display | |
Precautions for Purchasing the LB070W02-TMJ2 LCD Panel:
Authenticity and Quality Assurance:
Our LCD screen is an original replacement specifically designed for GPS systems.
We maintain sufficient stock ensuring availability.
Each screen undergoes rigorous testing to ensure optimal performance.
Upon shipment, you'll receive a tracking number to monitor delivery progress.
Swift Processing and Dispatch:
Orders are processed promptly, with goods dispatched within 48 hours of payment completion.
Secure Packaging:
We prioritize the safe delivery of our products.
Each LCD screen is carefully packaged with multiple layers of protection:
Anti-static bag
Bubble bag
Carton
Installation Precautions:
Refrain from using adhesive to affix the screen until its functionality is confirmed.
We cannot accept returns or issue refunds for screens that have been glued in place.
Testing and Verification:
Before installation, conduct a comprehensive test of the LCD screen.
Record a video during testing to ensure proper functioning.
Installation should proceed only after confirming the screen's operational status.
In case of any malfunction, provide us with the test video to facilitate resolution.
Power Off Before Handling:
Prior to testing or installation, ensure the device's power is switched off or the battery is disconnected.
Failure to do so may result in malfunction or damage.
Handle with Care:
LCD screens are delicate and susceptible to damage.
Exercise caution during testing and installation processes to prevent mishaps.
These precautions are designed to ensure a smooth and satisfactory experience with our LCD panel.
