LB050WQ1-TD01 LCD Display Panel 5.0 inch 480*272 LCD Screen Module
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LB050WQ1-TD01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LB050WQ1-TD01 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 480(RGB)×272, WQVGA 110PPI | Designed For: | Automotive Display、Portable Navigation、Portable DVD Player、MP3 PMP |
| Active Area: | 110.736(W)×62.288(H) Mm | Outline Dim.: | 124(W)×77.2(H)×6.3(D) Mm |
| Luminance: | 350 Cd/m² (Typ.) | Viewing Angle: | 65/65/60/50 (Typ.)(CR≥10) |
| Weight: | 90.0g (Typ.) | Interface Type: | Parallel RGB (1 Ch, 8-bit)40 Pins FPC |
Product Description
LB050WQ1-TD01 LCD Display Panel 5.0 inch 480*272 LCD Screen Module
LB050WQ1-TD01 LCD Panel Product details :
| Brand | LG |
| Model P/N | LB050WQ1-TD01 |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 480(RGB)×272, WQVGA 110PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 110.736(W)×62.288(H) mm |
| Bezel Opening | 113.8(W)×65.3(H) mm |
| Outline Dim. | 124(W)×77.2(H)×6.3(D) mm |
| Luminance | 350 cd/m² (Typ.) |
| View Direction | 6 o'clock |
| Viewing Angle | 65/65/60/50 (Typ.)(CR≥10) |
| Support Color | 16.7M 45% NTSC |
| Weight | 90.0g (Typ.) |
| Frame Rate | 60Hz |
| Treatment | Antiglare |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [6S2P], W/O Driver |
| Designed For | Automotive Display,Portable Navigation,Portable DVD Player,MP3 PMP |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 8-bit)40 pins FPC |
| Power Supply | 2.5/5.0V (Typ.)(VDD/AVDD) |
| Environment | Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C |
| LB050WQ1-TD01 LCD Display Panel 5.0 inch 480*272 LCD Screen Module | |
LB050WQ1-TD01 LCD Display Note :
Please ensure thorough verification of the following specifications – screen size, resolution, backlight type, interface type, and compatibility with your device – before proceeding with your order. If there is any uncertainty regarding compatibility, feel free to reach out to us for clarification at no cost.
Kindly furnish us with accurate contact details to facilitate prompt delivery of your item.
Should you wish for us to offer a reduced price to mitigate tariff implications, please inform us accordingly. However, please note that any associated risks shall be borne by you.
LB050WQ1-TD01 LCD Panel Shipping and Package :
SHIPPING Information for LB050WQ1-TD01 LCD Display :
We offer a variety of shipping options including Alibaba standard shipping, EMS, DHL, FedEx, and more. You can select your preferred shipping method during the checkout process.
Orders will typically be dispatched within 1-3 business days following the completion of payment. However, please note that certain products may require additional processing time depending on their stock availability.
Upon shipment, each order will be assigned a unique tracking number, which will be promptly provided to you for easy monitoring of your delivery.
To ensure the safe transit of your item, we utilize secure packaging consisting of an antistatic bag, bubble bag, bubble chamber, and a sturdy hard carton suited to the item's dimensions. This packaging approach is designed to minimize the risk of damage during transportation.
Reminder for LB050WQ1-TD01 LCD Display Purchase :
Kindly note that our listed price does not incorporate any customs taxes or fees applicable in the destination country. Whether you incur any taxes or fees upon Customs clearance at your destination hinges on the regulations enforced by the respective country.
To ensure seamless delivery, please verify and ensure the accuracy of your shipping details, including your address, postal code, phone number, and designated contact person, prior to finalizing your order. In the event you wish to have your order delivered to an alternate address, please notify us in advance and leave a message in our transaction platform to facilitate the necessary arrangements.
LB050WQ1-TD01 LCD Panel FAQ :
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: What's the different between original touch panel and compatible touch screen ?
A : Don't worry it . The compatible touch panel has the same function as original one .
Q: How long will I receive my goods of LB050WQ1-TD01 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for LG Mobile Display LB050WQ1-TD01 ?
A: We accept T/T , Paypal , western union .
