B125HAN02.0 1920*1080 12.5 inch TFT-LCD Panel LCD Screen
Product Details:
Place of Origin: | China |
Brand Name: | AUO |
Model Number: | B125HAN02.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | B125HAN02.0 | Diagonal Size: | 12.5" |
---|---|---|---|
Resolution: | 1920(RGB)×1080, FHD 176PPI | Active Area: | 276.48(W)×155.52(H) Mm |
Brightness: | 300 Cd/m² (Typ.) | Contrast Ratio: | 700 : 1 (Typ.) (TM) |
Designed For: | Laptop | Power Supply: | 3.3V (Typ.) |
Product Description
B125HAN02.0 1920*1080 12.5 inch TFT-LCD Panel LCD Screen
B125HAN02.0 LCD Panel Product details :
Brand | AUO |
Model P/N | B125HAN02.0 |
Diagonal Size | 12.5" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1920(RGB)×1080, FHD 176PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 276.48(W)×155.52(H) mm |
Bezel Opening | - |
Outline Size | 300.4(W)×180.9(H)×3(D) mm |
Surface | Antiglare, Hard coating (3H) |
Brightness | 300 cd/m² (Typ.) |
Contrast Ratio | 700:1 (Typ.) (TM) |
Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
Display Mode | AHVA, Normally Black, Transmissive |
Best View on | Symmetry |
Response Time | 25 (Typ.)(Tr+Td) |
Display Colors | 262K 50%NTSC |
Lamp Type | WLED, 15K hours, With LED Driver |
Frequency | 60Hz |
Touch Screen | Without |
Shape Style | Slim (PCBA Flat, T≤3.2mm) |
Application | Laptop |
Signal Interface | eDP (2 Lanes), eDP1.3, 30 pins Connector |
Input Voltage | 3.3V (Typ.) |
Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
B125HAN02.0 1920*1080 12.5 inch TFT-LCD Panel LCD Screen |
B125HAN02.0 LCD Panel Shipping and Package :
B125HAN02.0 LCD Panel FAQ :
Q: What does "We may ship a 100% compatible part number for your screen" mean?
A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.
Q: Do you accept the sample order?
A: Yes , sample order is welcome.
Q: How long is the warranty of product?
A: NEW Product warranty is 90days , the secondhand goods is 60days.
Q: How to order if I don’t know the lcd panel number ?
A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.
