TM060JYSP01 6.0 inch 720*1280 LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM060JYSP01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM060JYSP01 | Diagonal Size: | 6.0" |
|---|---|---|---|
| Resolution: | 720(RGB)×1280, WXGA 245PPI | Active Area: | 74.52(W)×132.48(H) Mm |
| Designed For: | Mobile Phone | Outline Dim.: | 77.32(W)×140.14(H)×0.5(D) Mm |
| Luminance: | 0 Cd/m² | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Environment: | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C |
Product Description
TM060JYSP01 6.0 inch 720*1280 LCD Display Panel
TM060JYSP01 LCD Panel Product details :
| Brand | TIANMA |
| Model P/N | TM060JYSP01 |
| Diagonal Size | 6.0" |
| Panel Type | a-Si TFT-LCD, CELL, Full Cell |
| Resolution | 720(RGB)×1280, WXGA 245PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 74.52(W)×132.48(H) mm |
| Bezel Opening | - |
| Outline Size | 77.32(W)×140.14(H)×0.5(D) mm |
| Brightness | 0 cd/m² |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.25+0.25 mm |
| Display Colors | 16.7M 70%NTSC |
| Frequency | - |
| Weight | - |
| Surface | Without Polarizer |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Transmissivity | 6% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
| Application | Mobile Phone |
| Driver IC | COGSuggest OTM1283A, OTM1288A, HX8394A, NT35521, NT35520 |
| Environment | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C |
TM060JYSP01 LCD Screen Notice:
Before placing your order, we kindly request you to carefully review and confirm whether the screen size, resolution, backlight type, interface type, and location are compatible with your laptop. If you are unsure or have any questions, please feel free to reach out to us for assistance.
To ensure prompt delivery, please provide us with your accurate contact details.
If you wish for us to declare a lower value to potentially reduce customs taxes, please inform us accordingly. However, please note that by doing so, you accept full responsibility for any associated risks.
TM060JYSP01 LCD Panel Shipping and Package :
TM060JYSP01 LCD Screen International Orders:
The buyer assumes responsibility for all customs fees and import taxes associated with international orders.
International orders may experience extended delivery times due to customs processing delays.
When shipping to Japan or South Korea via FedEx or DHL, the actual price of the item will be declared. Additionally, recipients in South Korea must provide a customs clearance serial number, for instance: "P123123456789". Please ensure to furnish us with the customs clearance serial number.
TM060JYSP01 LCD Screen About Item and Shipping Price:
For products that are seldom or never sold, the listed item price may not be accurate. Please contact us for an updated and precise quote.
Shipping prices to remote countries or islands may vary significantly. Kindly reach out to us for an accurate shipping quote tailored to your location.
TM060JYSP01 LCD Panel FAQ :
Q: Can you tested the TM060JYSP01 before shipping ?
A: Of course , our lcd panel TM060JYSP01 was Strictly tested before shipping.
Q: How to order TM060JYSP01 ?
A: We accept T/T , Paypal , western union .
Q: How long the warranty of the lcd TM060JYSP01 ?
A: 90 days .
Q: What happen if the lcd panel TM060JYSP01 I received can't work ?
A: TM060JYSP01 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
