LTM200KP01 20.0 inch 1600*900 tft LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Samsung |
| Model Number: | LTM200KP01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTM200KP01 | Screen Size: | 20.0inch |
|---|---|---|---|
| Resolution: | 1600(RGB)×900, HD+ 91PPI | Used For: | Desktop Monitor |
| Active Area: | 442.8(W)×249.075(H) Mm | Outline (mm): | 462.8(W)×272(H) ×17.5(D) Mm |
| Luminance: | 250 Cd/m² (Typ.) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Signal Type: | LVDS (2 Ch, 8-bit) , 30 Pins Connector | Environment: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
Product Description
LTM200KP01 20.0 inch 1600*900 tft LCD Display Panel
Product details :
| Samsung LCD Screen LTM200KP01 | |
|---|---|
| Manufacturer | Samsung |
| Model Name | LTM200KP01 |
| Screen Size | 20.0inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1600(RGB)×900, HD+ 91PPI |
| Pixel layout | RGB Vertical Stripe |
| Active Area | 442.8(W)×249.075(H) mm |
| Bezel Opening | 446.8(W)×253.2(H) mm |
| Outline (mm) | 462.8(W)×272(H) ×17.5(D) mm |
| Treatment | Antiglare (Haze 44%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 17/8 (Typ.)(Tr/Td) |
| View Direction | Symmetry |
| Operating Mode | PVA, Normally Black, Transmissive |
| Support Color | 16.7M 98% sRGB |
| Light Source | 4 pcs CCFL , 50K hours , Without Driver |
| Mass | 2.60Kgs (Max.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LTM200KP01 20.0 inch 1600*900 tft LCD Display Panel | |
