LTE283QV-F01 2.8 inch 320*240 TFT LCD display Panel for Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | Samsung |
| Model Number: | LTE283QV-F01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTE283QV-F01 | Screen Size: | 2.8 Inch |
|---|---|---|---|
| Resolution: | 320(RGB)×240, QVGA 141PPI | Active Area: | 57.59(W)×43.19(H) Mm |
| Outline Dim.: | 64.4 × 56.5 × 3.4 (H×V×D) | Luminance: | 250 Cd/m² (Typ.) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Signal Type: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
| Environment: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C | Used For: | Mobile Phone/ Handheld & PDA/ MP3 PMP /Gaming |
| Mass: | 26.0/28.0g (Typ./Max.) | ||
Product Description
LTE283QV-F01 2.8 inch 320*240 TFT LCD display Panel for Mobile Phone
LTE283QV-F01 LCD Panel Product details :
| Samsung LCD Screen LTE283QV-F01 | |
|---|---|
| Manufacturer | Samsung |
| Model Name | LTE283QV-F01 |
| Screen Size | 2.8inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 320(RGB)×240, QVGA 141PPI |
| Pixel layout | RGB Vertical Stripe |
| Active Area | 57.59(W)×43.19(H) mm |
| Bezel Opening | 61.0(W)×46.6(H) mm |
| Outline (mm) | 64.4 × 56.5 × 3.4 (H×V×D) |
| Treatment | - |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 35 (Typ.)(Tr+Td) ms |
| View Direction | - |
| Operating Mode | PVA, Normally Black, TMR |
| Support Color | 16.7M 37% NTSC |
| Light Source | 5S1P WLED , No Driver |
| Mass | 26.0/28.0g (Typ./Max.) |
| Used for | Mobile Phone Handheld & PDA MP3 PMP Gaming |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | Parallel RGB (1 ch, 8-bit) + SPI , 45 pins FPC |
| Voltage Supply | 2.8/2.8V (Typ.)(VDC/VCC) |
| Environment | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
| LTE283QV-F01 2.8 inch 320*240 TFT LCD display Panel for Mobile Phone | |
