Origing and New B154EW04 V9 15.4 inch 60Hz LCD Screen for AUO
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B154EW04 V9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | B154EW04 V9 | Resolution: | 1280(RGB)×800, WXGA, 98PPI |
|---|---|---|---|
| Active Area: | 331.2(W)×207(H) Mm | Brightness: | 200cd/m² (Typ.) |
| Contrast Ratio: | 400 : 1 (Typ.) (Transmission) | Viewing Angle: | 45/45/15/25 (Typ.) (CR≥10) |
| Response Time: | 8/17 (Typ.)(Tr/Td) Ms | Frequency: | 60Hz |
Product Description
Origing and New B154EW04 V9 15.4 inch 60Hz LCD Screen for AUO
B154EW04 V9 LCD Panel Product details :
| AUO LCD SCREEN B154EW04 V9 | |
|---|---|
| Panel Brand | AUO |
| Panel Model | B154EW04 V9 |
| Panel Size | 15.4" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1280(RGB)×800, WXGA, 98PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 331.2(W)×207(H) mm |
| Bezel Opening | 334.9(W)×210.7(H) mm |
| Outline Size | 344 (W) × 243.5 (H) × 6.5 (V) mm |
| Surface | Matte, Hard coating (3H) |
| Brightness | 200cd/m² (Typ.) |
| Contrast Ratio | 400 : 1 (Typ.) (Transmission) |
| Viewing Angle | 45/45/15/25 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 8/17 (Typ.)(Tr/Td) ms |
| Display Colors | 262K , 42% NTSC |
| Lamp Type | 1 pcs CCFL , 15K hours, with inverter |
| Frequency | 60Hz |
| Touch Screen | Without |
| Signal Interface | LVDS (1 ch, 6-bit) , 30 pins |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C |
| Origing and New B154EW04 V9 15.4 inch 60Hz LCD Screen for AUO | |
