CM500B1-001 New 5.0 inch 1080*1920 LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | CSOT |
| Model Number: | CM500B1-001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | CM500B1-001 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 1080(RGB)×1920, FHD 443PPI | Active Area: | 61.884(W)×110.016(H) Mm |
| Outline Size: | 63.484(W)×116.016(H)×0.45(D) Mm | Brightness: | 0 Cd/m² |
| Contrast Ratio: | 1500:1 (Typ.) (TM) | Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) |
| Response Time: | 35 (Typ.)(Tr+Td) | Application: | Mobile Phone |
Product Description
CM500B1-001 New 5.0 inch 1080*1920 LCD Screen Display
CM500B1-001 LCD Panel Product details :
| Brand | CSOT |
| Model P/N | CM500B1-001 |
| Diagonal Size | 5.0" |
| Panel Type | LTPS TFT-LCD, CELL, Full Cell |
| Resolution | 1080(RGB)×1920, FHD 443PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 61.884(W)×110.016(H) mm |
| Bezel Opening | - |
| Outline Size | 63.484(W)×116.016(H)×0.45(D) mm |
| Surface | - |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Glass Depth | 0.15+0.15 mm |
| Transmissivity | 3.15% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 70%NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | In-Cell Touch |
| Driver IC | COG Suggest FT8716, FT8736, HX83110A, XH83110B |
| Panel Weight | TBD |
| Application | Mobile Phone |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
