17.0 inch B170PW02 V0 frequency 60Hz tft LCD Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B170PW02 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | B170PW02 V0 | Diagonal Size: | 17.0'' |
|---|---|---|---|
| Display Area: | 367.2(horizontal)×229.5(vertical) Mm | Resolution: | 1440(RGB)×900, WXGA+, 99PPI |
| Contrast Ratio: | 400:1 (Typ.) (Transmission) | Viewing Angle: | 70/70/60/60 (Typ.) (CR≥10) |
| Brightness: | 385 Cd/m² (Typ.) | Outline Size: | 382.2 (horizontal) × 244.5 (vertical) × 7.3 (thickness) |
Product Description
17.0 inch B170PW02 V0 frequency 60Hz tft LCD Screen
B170PW02 V0 LCD Panel Product details :
| AUO LCD SCREEN B170PW02 V0 | |
|---|---|
| Panel Brand | AUO |
| Panel Model | B170PW02 V0 |
| Panel Size | 17.0" |
| Panel Type | LCM, a-Si TFT-LCD |
| Resolution | 1440(RGB)×900 WXGA+ 99PPI |
| Pixel Format | RGB vertical bars |
| Display Area | 367.2(horizontal)×229.5(vertical) mm |
| Bezel Opening | 371.2(horizontal)×233.5(vertical) mm |
| Outline Size | 382.2 (horizontal) × 244.5 (vertical) × 7.3 (thickness) |
| Surface | Specular (Haze 0%), Anti-Reflection Treatment |
| Brightness | 385 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (Transmission) |
| Viewing Angle | 70/70/60/60 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 12/4 (Typ.)(Tr/Td) ms |
| Display Colors | 262K , 52% NTSC |
| Lamp Type | 2 pcs CCFL , 10K hours, without driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Signal Interface | 30 pins LVDS (2 ch, 6-bit) , terminal |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| 17.0 inch B170PW02 V0 frequency 60Hz tft LCD Screen | |
