Supplying 6.5 injch C065GW04 V0 72PPI TFT LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | C065GW04 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | C065GW04 V0 | Diagonal Size: | 6.5'' |
|---|---|---|---|
| Viewing Angle: | 55/55/45/60 (Typ.)(CR≥10) | Display Area: | 143.4(W)×79.326(H) Mm |
| Resolution: | 400(RGB)×240 WQVGA 72PPI | Contrast: | 600 : 1 (Min.) [Transmission] |
Product Description
Supplying 6.5 injch C065GW04 V0 72PPI TFT LCD Display
C065GW04 V0 LCD Panel Product details :
| AUO LCD Screen C065GW04 V0 | |
|---|---|
| Panel Brand | AUO |
| Panel Model | C065GW04 V0 |
| screen size | 6.5inches |
| Panel Type | LCM, a-Si TFT-LCD |
| Resolution | 400(RGB)×240 WQVGA 72PPI |
| Pixel configuration | RGB vertical bars |
| Display size | 143.4(W)×79.326(H) mm |
| visible size | 145.1(W)×81.1(H) mm |
| physical dimension | 157(W)×94.4(H)×13.6(D) mm |
| surface | Matte, Reflectance 1.0% (Max.) |
| Brightness (cd/m²) | 450 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Min.) [Transmission] |
| Viewing Angle | 80/80/80/80 (Typ.) (CR≥10) |
| responding speed | 35 (Typ.)(Tr+Td) |
| display mode | AHVA, Normally Black, Transmissive |
| Number of colors | 16.7M , 55% NTSC |
| Backlight type | 6S3P WLED , 10K hours, without driver |
| refresh rate | 60Hz |
| screen weight | 150±15g |
| signal system | 60 pins Parallel RGB (1 ch, 8-bit) , FPC |
| Supply voltage | 3.3/13.0/15.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| maximum rating | Operating temperature: -30 ~ 80 °C ; Storage temperature: -40 ~ 85 °C ; Vibration resistance: 2.9G (28.4 m/s²) |
| Supplying 6.5 injch C065GW04 V0 72PPI TFT LCD Display | |
C065GW04 V0 LCD Module Reminder:
Product Information:
While product information is sourced from the internet, we assure you that our pictures are genuine representations of the product. We ship your order exactly as depicted in our images. To avoid any inconvenience, please compare our pictures with your desired product before making a purchase. Please note that return postal costs for an incorrect purchase are at the buyer's expense.
Order Processing Time:
Your order will be processed and shipped out within 2-7 working days from the date of purchase.
Arrival Time:
The estimated arrival time for your order is between 30-60 days, or even longer, depending on the postal service in your country. If you haven't received your product within 60 days, we kindly ask for your patience and suggest waiting a few more days.
Shipping Method:
If you have chosen the shipping option "China Post Ordinary Small Packet Plus," please be aware that this method does not provide tracking outside of China. We appreciate your understanding and patience in waiting for your package to arrive. Thank you for your cooperation.
C065GW04 V0 LCD Panel Shipping and Package :
C065GW04 V0 LCD Module Return Policy:
Return Conditions:
Returned products must be in their original condition, including the box, packaging, and all other accessories.
Returns that result from customer error will be subject to an actual shipping fee deduction from the refund.
Refund or Replacement:
Upon receipt of the returned item, we will inspect it to ensure it meets our return conditions.
Depending on the circumstances, we will offer a partial or full refund or a replacement at our cost.
Contact Us:
To initiate a return or if you have any questions regarding the return process, please contact us at [sales@yongs-hk.com]. Our dedicated customer service team will be happy to assist you.
Please note that shipping fees and YONGS (Your Own Negligence Goods Shipping) charges are non-refundable.
C065GW04 V0 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of C065GW04 V0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How can I trace my order of C065GW04 V0 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can I pay my order of C065GW04 V0 via credit card ?
A:Yes!you can use your credit card through your Paypal account.
C065GW04 V0 LCD Module Contact Us:
We are dedicated to providing exceptional customer service. If you have any questions or concerns regarding the C065GW04 V0 LCD Module, please do not hesitate to reach out to us. Our team is committed to promptly addressing all inquiries and providing the assistance you need.
You can email us at [sales@yongs-hk.com]. We strive to respond to all messages within 24 hours. However, please understand that there may be a delay in response during non-business hours.
Your satisfaction is our priority, and we look forward to assisting you with any issues or queries you may have. Thank you for choosing our products.
