F055A31-602 5.5 inch 1080*1920 TFT LCD panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | F055A31-602 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | F055A31-602 | Resolution: | 1080(RGB)×1920, FHD 403PPI |
|---|---|---|---|
| Diagonal Size: | 5.5" | Number Of Colors: | 16.7M 70%NTSC |
| Pixel Format: | RGB Vertical Stripe | Used For: | Mobile Phone |
| Treatment: | Without Polarizer | Luminance: | 0 Cd/m² |
| Contrast Ratio: | 1000:1 (Typ.) (TM) | Support Color: | 16.7M 70%NTSC |
Product Description
F055A31-602 5.5 inch 1080*1920 TFT LCD panel
F055A31-602 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | F055A31-602 |
| Diagonal Size | 5.5" |
| Panel Type | LTPS TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Dim. | 69.64(H)×126.56(V)×1(D) mm |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 4.2% (Typ.)(with Polarizer) |
| Support Color | 16.7M 70%NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Suggest ILI7807D |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
