NL6448BC33-31 10.4 inch 640*480 60Hz 350 Typ lcd display screen for NEC
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC33-31 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NL6448BC33-31 | Diagonal Size: | 10.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 76PPI | Display Size: | 211.2(W)×158.4(H) Mm |
| Brightness (cd/m²): | 350 (Typ.) | Visual Size: | 215.4(W)×161.8(H) Mm |
| Support Color: | 262K, 43% NTSC | Backlight: | CCFL [2 Pcs] |
| Signal System: | CMOS (1 Ch, 6-bit), Connector, 31 Pins | Contrast Ratio: | 350: 1 (Typ.) [Transmission] |
Product Description
NL6448BC33-31 10.4 inch 640*480 60Hz 350 Typ lcd display screen for NEC
NL6448BC33-31 LCD Panel Product details :
| NEC LCD SCREEN NL6448BC33-31 | |
|---|---|
| Manufacturer | NEC |
| Model Name | NL6448BC33-31 |
| Screen Size | 10.4 inches |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 640(RGB)×480 [VGA] 76PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 211.2 × 158.4 mm (H×V) |
| physical dimension | 243 × 185.1 × 11.5 mm (H×V×D) |
| Visual size | 215.4 × 161.8 mm (H×V) |
| Surface treatment | Clear, Antireflection |
| Brightness (cd/m²) | 350 (Typ.) |
| Contrast | 350: 1 (Typ.) [Transmission] |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 50/50/40/45 (Typ.)(CR≥10) |
| responding speed | 15/70 (Typ.)(Tr/Td) ms |
| Number of colors | 262K, 43% NTSC |
| Backlight type | 2 pcs CCFL, without driver |
| Screen weight | 530/550g (Typ./Max.) |
| Refresh rate | 60Hz |
| signal system | CMOS (1 ch, 6-bit), connector, 31 pins |
| Supply voltage | 3.3/5.0V (Typ.)(VCC) |
| Maximum rating | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| NL6448BC33-31 10.4 inch 640*480 60Hz 350 Typ lcd display screen for NEC | |
NL6448BC33-31 LCD Screen Specification :
Installation Instructions: Not Included. Note: There is a layer of polarizer film under the protective film on the front of the panel. If the display appears blurry after installation, please remove the polarizer film.
Quality Assurance: Prior to dispatch, we conduct comprehensive quality checks and testing to ensure product reliability and performance.
Compatibility: This item is suitable for replacing touch panels that are broken, damaged, cracked, or otherwise unusable.
