For NEC 8.4 inch NL6448BC26-26D 640*480 lcd screen module
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC26-26D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NL6448BC26-26D | Diagonal Size: | 8.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480 VGA 95PPI | Display Size: | 170.88(W)×128.16(H) Mm |
| Physical Dimension: | 200 × 152 × 8.7 (H×V×D) | Visual Size: | 174.0(H)×131.4(V) Mm |
| Luminance: | 500 Cd/m² (Typ.) | Contrast: | 1000:1 (Typ.) (transmission) |
| Response Time: | 3/15 (Typ.)(Tr/Td) Ms | Weight: | 260/280g (Typ./Max.) |
Product Description
For NEC 8.4 inch NL6448BC26-26D 640*480 lcd screen module
NL6448BC26-26D LCD Panel Product details :
| NEC LCD SCREEN NL6448BC26-26D | |
|---|---|
| manufacturer | NEC |
| Model Name | NL6448BC26-26D |
| screen size | 8.4 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 640(RGB)×480 [VGA] 95PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 170.88(H)×128.16(V) mm |
| physical dimension | 200(H)×152(V) ×8.7(D) mm |
| Visual size | 174.0(H)×131.4(V) mm |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Responding time | 3/15 (Typ.)(Tr/Td) |
| Number of color | 262K 40% NTSC |
| Backlight type | WLED [3 strings] , 70K hours , W/O Driver |
| Panel weight | 260/280g (Typ./Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | CMOS (1 ch, 6-bit) 31 pins Connector |
| Supply voltage | 3.3/5.0V (Typ.) |
| Maximum rating | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| For NEC 8.4 inch NL6448BC26-26D 640*480 lcd screen module | |
NL6448BC26-26D LCD Screen Item Condition :
The item is classified as Grade A Condition, ensuring its optimal quality and functionality, with a guarantee of 100% working order. We take great care to provide products that meet high standards of performance and reliability.
However, please ensure that the connector location of this screen matches with the connector on your old screen before installation. This precaution ensures compatibility and seamless integration with your device. If you have any doubts or questions regarding compatibility, please don't hesitate to reach out to our customer service team for assistance. We are here to help you make an informed decision and ensure a smooth replacement process.
