H546UAN01.0 CELL 5.5 inch 2160*3840 LCD screen Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | H546UAN01.0 CELL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | H546UAN01.0 CELL | Diagonal Size: | 5.5" |
|---|---|---|---|
| Panel Type: | LTPS TFT-LCD, CELL , COG | Resolution: | 2160(RG/BR/GB)×3840, UHD 658PPI |
| Pixel Layout: | Rainbow-RGB | Active Area: | 68.04(W)×120.96(H) Mm |
| Used For: | Mobile Phone ，HMD VR AR | Luminance: | 0 (cd/m²) |
| Contrast Ratio: | 1000 : 1 (Typ.) (TM) | Support Color: | 16.7M 94% NTSC |
Product Description
H546UAN01.0 CELL 5.5 inch 2160*3840 LCD screen Display Panel
H546UAN01.0 CELL LCD Panel Product details :
| Brand | AUO |
| Model P/N | H546UAN01.0 CELL |
| Diagonal Size | 5.5" |
| Panel Type | LTPS TFT-LCD, CELL , COG |
| Resolution | 2160(RG/BR/GB)×3840, UHD 658PPI |
| Pixel Format | Rainbow-RGB |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Dim. | 69.64(W)×128.56(H)×0.49(D) |
| Treatment | Clear, Hard coating (1H) |
| Luminance | 0 (cd/m²) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 15/15 (Typ.)(Tr/Td) ms |
| Viewing Angle | 70/70/70/70 (Typ.)(CR≥100) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Glass Thickness | - |
| Transmissivity | 3% (Typ.)(with APCF) |
| Support Color | 16.7M 94% NTSC |
| Light Source | No B/L |
| Weight | 10.1g |
| Designed For | Mobile Phone ,HMD VR AR |
| Frame Rate | - |
| Touch Panel | Without |
| Driver IC list | Built-in COG NT35950 |
| Interface Type | MIPI (2 ch, 4 data lanes) , 60 pins Connector |
| Power Supply | 1.85/1.35V (Typ.)(DVDD/VDDI) |
| Environment | Storage Temp.: -55 ~ 125 °C Operating Temp.: -40 ~ 85 °C |
