9.0 inch lcd module HSD090IDW1-A01 800*480 lcd display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | PANDA |
| Model Number: | HSD090IDW1-A01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD090IDW1-A01 | Diagonal Size: | 9.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 104PPI | Active Area: | 198(W)×112.08(H) Mm |
| Bezel Opening: | 201.1(W)×115.15(H) Mm | Outline Dim.: | 210.7(H)×126.4(V)×5.6(D) Mm |
| Treatment: | Antiglare, Hard Coating (3H) | Weight: | 240g (Typ.) |
| Designed For: | Digital Photo Frame / Portable DVD Player | Interface Type: | TTL (1 Ch, 6/8-bit) , 60 Pins FPC |
Product Description
9.0 inch lcd module HSD090IDW1-A01 800*480 lcd display panel
HSD090IDW1-A01 LCD Panel Product details :
| HannStar LCD Screen HSD090IDW1-A01 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD090IDW1-A01 |
| Diagonal Size | 9.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×480, WVGA 104PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 198(W)×112.08(H) mm |
| Bezel Opening | 201.1(W)×115.15(H) mm |
| Outline Dim. | 210.7(H)×126.4(V)×5.6(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 200 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 5.5/10.5(Typ.)(Tr/Td) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.2M 46% NTSC |
| Light Source | WLED [3S7P] , 20K hours , W/O Driver |
| Weight | 240g (Typ.) |
| Designed For | Digital Photo Frame / Portable DVD Player |
| Touch Panel | Without |
| Interface Type | TTL (1 ch, 6/8-bit) , 60 pins FPC |
| Power Supply | 3.3/10/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 9.0 inch lcd module HSD090IDW1-A01 800*480 lcd display panel | |
HSD090IDW1-A01 LCD Screen Note Before Purchase:
Fragility of Laser Lens: Please be aware that the laser lens included with this product is fragile. It is crucial to assess whether you have the necessary expertise and resources to handle and replace the laser lens or laser head, as well as any other accessories that may be required. If you are uncertain about your capabilities or resources, we strongly advise seeking assistance from qualified professionals.
Professional Installation Recommended: After purchasing our product, we highly recommend engaging the services of experienced professionals for installation. These individuals possess the knowledge and skills required to safely and accurately replace components, minimizing the risk of damage to both the product and your machine.
Pre-Installation Testing: Prior to installation, it is essential to conduct thorough testing to ensure the compatibility and functionality of the product. This step helps prevent any potential issues or damage to your machine during the installation process. Additionally, some lasers may require opening protection points before installation, so it is important to follow the manufacturer's guidelines carefully.
HSD090IDW1-A01 LCD Screen Payment:
Thank you for considering purchasing the HSD090IDW1-A01 LCD screen from us. Before proceeding with your order, we kindly request that you review the following payment guidelines:
Price Confirmation: Prior to placing your order, we recommend confirming the price and all relevant details with our supplier. This ensures transparency and accuracy in your transaction, helping to avoid any misunderstandings or discrepancies.
Read Description Carefully: We encourage you to carefully read the entire product description provided. It contains essential information about the HSD090IDW1-A01 LCD screen, including specifications, features, and any terms and conditions associated with the purchase. By thoroughly reviewing the description, you can make an informed decision and ensure that the product meets your requirements.
Agree to Transaction: By proceeding with the purchase, you acknowledge that you have read, understood, and agree to the terms of the transaction as outlined in the product description. This includes but is not limited to pricing, payment methods, shipping details, and any applicable policies or procedures.
HSD090IDW1-A01 LCD Panel Shipping and Package :
HSD090IDW1-A01 LCD Screen Shipping Note:
Shipping Considerations:
When it comes to shipping your order to your home, we want to ensure a smooth and timely delivery process. Depending on your location, we offer the following shipping options:
DHL/UPS/FEDEX: Estimated delivery time ranges from 2 to 7 working days. These courier services provide fast and reliable shipping, ensuring your order reaches you promptly.
EMS (Express Mail Service): Estimated delivery time ranges from 5 to 15 working days. EMS offers a cost-effective shipping solution with reasonable delivery times.
Remote Shipping Address:
Please be mindful of your shipping address. In the event that your shipping address is considered remote, we will reach out to you to make necessary adjustments. Shipping to remote areas may incur additional costs due to logistical challenges. If your address falls into a remote area category, there will be a remote area surcharge of $30 USD. We appreciate your understanding and cooperation in this matter.
HSD090IDW1-A01 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of HSD090IDW1-A01 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of HSD090IDW1-A01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of HSD090IDW1-A01 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
