10.1 inch LCD Screen Panel HSD100IFW1-A04 LCD Display Module
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD100IFW1-A04 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD100IFW1-A04 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1024(RGB)×600, WSVGA 118PPI | Active Area: | 220.416(W)×129.15(H) Mm |
| Bezel Opening: | 223.42(W)×132.15(H) Mm | Outline Size: | 235×145.8×5.8 (H×V×D) |
| Surface: | Antiglare, Hard Coating (3H) | Lamp Type: | WLED , 10K Hours , With LED Driver |
| Application: | Netbook PC / Digital Photo Frame / Portable DVD Player | Signal Interface: | LVDS (1 Ch, 6-bit) , Connector 30 Pins |
Product Description
10.1 inch LCD Screen Panel HSD100IFW1-A04 LCD Display Module
HSD100IFW1-A04 LCD Panel Product details :
| HannStar LCD Screen HSD100IFW1-A04 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD100IFW1-A04 |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 118PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 220.416(W)×129.15(H) mm |
| Bezel Opening | 223.42(W)×132.15(H) mm |
| Outline (mm) | 235×145.8×5.8 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Response | 5/20 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K 47% NTSC |
| Backlight | WLED , 10K hours , With LED Driver |
| Used for | Netbook PC / Digital Photo Frame / Portable DVD Player |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6-bit) , Connector 30 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 10.1 inch LCD Screen Panel HSD100IFW1-A04 LCD Display Module | |
Payment Instructions for HSD100IFW1-A04 LCD Screen :
Payment Method:
You can conveniently use your credit card to pay through PayPal or ALI.
Sales Tax for Texas Residents:
Texas residents are required to add 8.25% for sales tax to their total purchase amount.
International Buyers:
If you are an international buyer, kindly email us your address for accurate calculation of shipping costs. This applies if shipping costs are not displayed at checkout or if you require the item to be shipped via fast courier service.
Assistance and Inquiries:
Should you have any questions or require further assistance, please do not hesitate to contact us. We are here to help!
HSD100IFW1-A04 LCD Panel Shipping and Package :
Shipping Details for HSD100IFW1-A04 LCD Screen :
Shipping Options:
Economy: 15-50 days
Standard: 10-35 days
Accelerated: 4-7 days
Shipment Processing:
Your item will be dispatched within 3 working days upon receipt of full payment. Estimated delivery time is 2-4 weeks. If you haven't received the item within 21 working days post full payment, kindly send us an email for assistance.
Delays Due to Holidays or Weather:
In case of holidays in China or unexpected weather conditions, there might be delays in shipment. Rest assured, we prioritize organizing the shipment promptly. We appreciate your understanding and support during such situations.
Shipping Address:
Please ensure the shipping address provided during PayPal payment is accurate and approved. We only ship to the address specified in PayPal. Any discrepancy leading to non-delivery due to an invalid address registered on PayPal will not be eligible for full refund or replacement.
Contact Number Requirement:
To expedite the delivery process, kindly provide your contact number. Failure to provide a valid phone number may result in delayed delivery or inability to deliver the item.
Special Shipping Consideration:
Certain highly magnetic products, such as servomotors, can only be shipped via EMS delivery for safety reasons. Please note this restriction when ordering such items.
Warranty and Returns Policy for HSD100IFW1-A04 LCD Screen:
Warranty Coverage:
We offer a 60-day warranty for defective items. If your product is found to be defective within this period, you are eligible for warranty coverage.
Shipping for Defective Products:
For defective items covered under warranty, we will cover the shipping costs for both returning the defective product to us and sending a replacement item to you.
Returns for Reasons Other Than Defects:
If you wish to return the product for reasons other than it being defective, you are responsible for the return shipping costs. However, we will cover the shipping costs for sending the original product to you.
Coverage Duration:
Return shipping is covered only for defective items returned within 60 days from the date of purchase. After this period, we will not accept returns for any reason.
Restocking Fee:
We do not charge any restocking fee for returns.
Please note: Our return policy is straightforward and aims to provide you with a hassle-free experience. However, it's important to adhere to the specified timeframes and conditions outlined above for eligibility.
HSD100IFW1-A04 LCD Panel FAQ :
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Do you accept the HSD100IFW1-A04 sample order?
A: Yes , sample order is welcome.
Q: Can you test the lcd panel HSD100IFW1-A04 before shipping ?
A: Of Course . You can take a rest that our lcd panel will be tested ok before shipping.
Q: How long is the warranty of HSD100IFW1-A04 ?
A: 90DAYS.
Q: How long will I receive my goods of lcd HSD100IFW1-A04 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
