HSD220MKW1-A00 LCD Screen Display Original 22.0 inch 1680*1050 for HannStar
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD220MKW1-A00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD220MKW1-A00 | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1680(RGB)×1050, WSXGA+ 90PPI | Active Area: | 473.76(W)×296.1(H) Mm |
| Bezel Opening: | 477.7(W)×300.1(H) Mm | Outline(mm): | 493.7(W)×320.1(H)×17(D) |
| Response: | 5 (Typ.)(Tr+Td) Ms | Mass: | 3.05±0.20Kgs |
| Used For: | Desktop Monitor | Signal Type: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
| High Light: | HSD220MKW1-A00,HSD220MKW1-A00 LCD Screen Display |
||
Product Description
HSD220MKW1-A00 Original 22.0 inch 1680*1050 LCD Screen Display for HannStar
HSD220MKW1-A00 LCD Panel Product details :
| HannStar LCD Screen HSD220MKW1-A00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD220MKW1-A00 |
| Diagonal Size | 22.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1680(RGB)×1050, WSXGA+ 90PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 473.76(W)×296.1(H) mm |
| Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Dim. | 493.7(H)×320.1(V) ×17(D) mm |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 5 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 76% NTSC |
| Light Source | CCFL [4 pcs] , 40K hours , W/O Driver |
| Weight | 3.05±0.20Kgs |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HSD220MKW1-A00 Original 22.0 inch 1680*1050 LCD Screen Display for HannStar | |
HSD220MKW1-A00 LCD Screen Note:
Please be advised that the images displayed are for illustrative purposes only, and the part depicted may not necessarily represent the specific item you will receive. Our inventory undergoes frequent restocking, leading to potential variations in appearance. Although we strive for 100% accuracy in our information, compatibility details are provided as a courtesy to our customers and should not be considered as warranties, whether implied or otherwise, regarding the accuracy of such information.
We strongly encourage customers to exercise due diligence and independently verify that the part(s) they are ordering align with their specific requirements. While we make every effort to ensure the correctness of our product details, individual applications may vary, and it is the responsibility of the customer to certify that the selected part(s) are indeed the correct ones for their intended purpose.
In instances where the aforementioned conditions cannot be accepted or may pose concerns, we kindly request customers to communicate any specific reservations or requirements in advance. Clear communication about any specific expectations or limitations will enable us to better assist you and provide a more tailored service. We value transparency and aim to address any concerns you may have to ensure a positive and satisfactory experience with our products.
HSD220MKW1-A00 LCD Panel Shipping and Package :
HSD220MKW1-A00 LCD Screen After Service:
Our commitment to customer satisfaction extends beyond the purchase of the HSD220MKW1-A00 LCD Screen. We offer a hassle-free 5-day return policy, allowing you to return the item without providing a specific reason. Additionally, we provide a robust 90-day warranty for this product to ensure your peace of mind.
However, it's important to note that certain circumstances fall outside the scope of our warranty coverage. Damage caused by man-made factors or natural disasters is not eligible for warranty claims. Examples of such instances include improper installation, physical damage such as nicks or tube touch issues, and malfunctions due to mishandling or improper feeding.
To maintain the integrity of our warranty, we have implemented measures to identify potential abuse. Products sold by our store are equipped with fragile tags that serve as a warranty indicator. Any tampering or removal of these tags during the warranty period will void the warranty. We kindly request customers to exercise caution and refrain from damaging or removing these tags.
Furthermore, any disconnection or loss of the product will be considered a waiver of the warranty, and in such cases, we cannot accept any responsibility for replacement or repair. It is crucial for customers to pay attention to the proper handling and care of the product to ensure its longevity and performance.
While we strive to provide exceptional service, it is essential for customers to adhere to these terms and conditions to facilitate a smooth after-service experience. We appreciate your understanding and cooperation in maintaining the integrity of our warranty program.
HSD220MKW1-A00 LCD Screen Tariff:
a. Import duties, taxes, and charges are not included in the item price or shipping charges. These additional costs are the sole responsibility of the buyer. It's important to note that these charges may vary depending on your country's customs regulations and import policies.
b. Prior to bidding or making a purchase, we strongly recommend checking with your country's customs office to ascertain the specific import duties, taxes, and charges that may apply to the HSD220MKW1-A00 LCD Screen. Understanding these additional costs in advance will enable you to make an informed decision and avoid any unexpected financial implications.
We understand that navigating international trade regulations can be complex, and we want to ensure that our customers have a transparent and seamless experience. By being aware of the potential additional charges associated with importing the product, you can plan accordingly and ensure a smoother customs clearance process.
If you have any specific questions or concerns related to tariffs or customs duties, please feel free to reach out to our customer service team.
HSD220MKW1-A00 LCD Panel FAQ :
Q: Can I pay my goods HSD220MKW1-A00 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods HannStar HSD220MKW1-A00 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: How long is the warranty of HSD220MKW1-A00 ?
A: 90days warranty .
Q: Can You declare my order of sharp lcd panel HSD220MKW1-A00 at a very low value ?
A: Yes , we can . pls inform us before shipping .
