HSD190ME13-D10 19.0 inch TFT LCD Screen 1280*1024 LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD190ME13-D10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD190ME13-D10 | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1280(RGB)×1024, SXGA 86PPI | Active Area: | 376.32(W)×301.056(H) Mm |
| Bezel Opening: | 380.2(W)×305.0(H) Mm | Outline(mm): | 396 × 324 × 18 (H×V×D) |
| Treatment: | Antiglare, Hard Coating (3H) | Mass: | 2.60±0.15Kgs |
| Used For: | Desktop Monitor | Signal Type: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
| High Light: | HSD190ME13-D10,19.0 inch TFT LCD Screen |
||
Product Description
HSD190ME13-D10 19.0 inch TFT LCD Screen 1280*1024 LCD Display
HSD190ME13-D10 LCD Panel Product details :
| HannStar LCD Screen HSD190ME13-D10 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD190ME13-D10 |
| Diagonal Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 376.32(W)×301.056(H) mm |
| Bezel Opening | 380.2(W)×305.0(H) mm |
| Outline(mm) | 396 × 324 × 18 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 75/75/75/60 (Typ.)(CR≥10) |
| Response | 1.5/3.5 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.2M 73% NTSC |
| Backlight | 4 pcs CCFL , 40K hours , No Driver |
| Mass | 2.60±0.15Kgs |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| HSD190ME13-D10 19.0 inch TFT LCD Screen 1280*1024 LCD Display | |
Quality Assurance for HSD190ME13-D10 LCD Display:
Undamaged Screens:
Each HSD190ME13-D10 LCD display undergoes a meticulous inspection process to guarantee that it reaches you in pristine condition. We take extra care to ensure that the screens are free from any damage, ensuring a flawless visual experience upon installation.
Zero Dead Pixels:
Our commitment to excellence extends to ensuring that every LCD display is free from dead pixels. Through rigorous testing, we identify and eliminate any defective units, ensuring that you receive a display that meets the highest industry standards.
Comprehensive Testing:
Before any HSD190ME13-D10 LCD display leaves our facility, it undergoes comprehensive testing procedures. Our quality control team meticulously examines each unit to verify its functionality, color accuracy, and overall performance. This rigorous testing process is in place to guarantee that every display meets or exceeds your expectations.
Customer Satisfaction Guarantee:
We prioritize your satisfaction with our products. Our commitment to quality is not just about delivering a product; it's about ensuring that you are delighted with your purchase. If, for any reason, you are not satisfied with the quality of your HSD190ME13-D10 LCD display, please contact us, and we will promptly address your concerns.
HSD190ME13-D10 LCD Panel Shipping and Package :
Shipping Information for HSD190ME13-D10 LCD Display:
Quality Assurance in Shipping:
Before dispatching any HSD190ME13-D10 LCD display, we prioritize quality by subjecting each unit to strict testing procedures. This ensures that the product you receive meets our high standards for performance and reliability.
Timely Shipment:
Once your payment is confirmed, we aim to process and ship your order promptly. Expect your HSD190ME13-D10 LCD display to be dispatched within 3 working days after payment. Our commitment to swift processing is part of our dedication to providing you with a seamless purchasing experience.
Customs Duty Responsibility:
Please be aware that the buyer is responsible for any customs duty fees associated with the shipment. Customs regulations vary by country, and it's important to consider and fulfill any duty obligations imposed by your local customs authorities.
International Shipping Timeframe:
The shipping duration for international orders typically ranges from 10 to 45 business days. Please note that these estimates are general guidelines, and actual delivery times may vary based on factors such as destination, customs clearance, and local postal services.
Communication for Delayed Shipments:
If, for any reason, you do not receive your parcel within the expected timeframe, we encourage you to contact us promptly. We understand the importance of your order and will work diligently to investigate and resolve any delays. Your satisfaction is our priority, and we are committed to providing transparent and responsive communication throughout the shipping process.
HSD190ME13-D10 LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of HSD190ME13-D10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of HSD190ME13-D10 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: If I place order now,when will you ship the goods of HSD190ME13-D10 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How to make payment of HSD190ME13-D10 ?
A: We accept T/T , Paypal , western union .
Customer Service Hours for HSD190ME13-D10 LCD Display:
We are dedicated to providing excellent customer service to ensure your satisfaction with our HSD190ME13-D10 LCD display. Our knowledgeable and friendly support team is available to assist you with any questions or concerns you may have. Here are the details of our service hours:
Service Hours:
Beijing Time: 8:00 - 12:00 (Morning), 13:30 - 18:00 (Afternoon)
During these specified hours, our team is actively available to address your inquiries, provide information, and offer assistance with any issues related to the HSD190ME13-D10 LCD display.
24-Hour Customer Service:
While our regular service hours are outlined above, we understand that your needs may arise outside of these times. Therefore, we have a dedicated 24-hour customer service team that is ready to assist you around the clock. Regardless of the time zone or when you encounter an issue, you can reach out to our customer service team for prompt and reliable support.
Contacting Us:
For immediate assistance during service hours, you can contact us via the provided communication channels.
Outside of regular service hours, our 24-hour customer service team will continue to be available to address urgent matters.
