HSD190ME12-A02 LCD Screen Display 19.0 Inch 1280*1024 LCD Panel Module
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD190ME12-A02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD190ME12-A02 | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1280(RGB)×1024, SXGA 86PPI | Active Area: | 376.32(W)×301.056(H) Mm |
| Outline(mm): | 404.2(W)×330(H) Mm | Treatment: | Antiglare, Hard Coating (3H) |
| Response: | 12 (Typ.)(Tr+Td) | Color Depth: | 16.2M 74% NTSC |
| Panel Weight: | 2.35±0.12Kgs | Application: | Desktop Monitor |
| High Light: | HSD190ME12-A02,HSD190ME12-A02 LCD Screen Display,1280*1024 LCD Panel Module |
||
Product Description
HSD190ME12-A02 LCD Screen display 19.0 inch 1280*1024 lcd panel module
HSD190ME12-A02 LCD Panel Product details :
| HannStar LCD Screen HSD190ME12-A02 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD190ME12-A02 |
| Diagonal Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 376.32(W)×301.056(H) mm |
| Outline Size | 404.2(W)×330(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 70/70/65/65 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 12 (Typ.)(Tr+Td) |
| Display Colors | 16.2M 74% NTSC |
| Lamp Type | 4 pcs CCFL , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 2.35±0.12Kgs |
| Application | Desktop Monitor |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HSD190ME12-A02 LCD Screen display 19.0 inch 1280*1024 lcd panel module | |
HSD190ME12-A02 LCD Screen Please confirm before buying :
1. Model, Screen Size, and Part Number Verification:
- Prior to finalizing your order, double-check your device's model, screen size, and part number to ensure compatibility with the HSD190ME12-A02 LCD Screen.
- If uncertainty arises regarding compatibility, kindly share the specific model number and provide clear photos of your original screen. Our dedicated support team is here to assist you in making an informed decision.
2. Compatible Model Assurance:
- The LED panel we dispatch may have a compatible model number, which may not be an exact match to the model of your original screen. However, rest assured that we guarantee its compatibility with your device by 100%.
- Our commitment is to provide you with a replacement that seamlessly fits and functions with your device, offering an optimal visual experience.
3. Pre-Shipment Testing and Adhesive Tape:
- To ensure the highest quality, all items are rigorously tested before being shipped to you. This testing process aims to guarantee that the HSD190ME12-A02 LCD Screen meets our stringent quality standards.
- Please note that adhesive tape is not included by default. If you require adhesive tape for installation, kindly leave a message during the ordering process. We are more than happy to accommodate your specific needs to enhance the convenience of the installation.
HSD190ME12-A02 LCD Panel Shipping and Package :
HSD190ME12-A02 LCD Screen Returns Policy :
Return Period :
All unwanted items must be returned within 30 days from the date of purchase. We acknowledge that preferences and requirements may change, and we are here to accommodate your needs.
Return Responsibility:
Customers are responsible for the return of unwanted items. This includes covering any associated shipping or courier costs. We appreciate your cooperation in this matter, as it allows us to maintain competitive pricing and continue providing high-quality products and services.
Return Authorization:
For all product returns, it is mandatory to obtain a valid Return Merchandise Authorization (RMA) number. This number serves as a unique identifier for your return and helps us process it efficiently. Additionally, a detailed description of the fault or reason for return is required to assist us in addressing the issue promptly.
RMA Number Placement:
To ensure a seamless return process, please clearly mark the RMA number on the outside of the return packaging. This step is crucial in streamlining the identification and processing of your return upon receipt.
Courier Damages Notification:
In the unfortunate event that your product is damaged during transit by the courier, please notify us within 24 hours of receiving the item. This prompt communication allows us to initiate the necessary steps to address the issue and expedite the resolution process.
Warranty Information:
All warranty claims are "return to base." This means that the responsibility for returning the product to us lies with the customer. Please package the item securely to prevent any further damage during transit. It's important to note that YONGS is not liable for any damages that may occur while returning the parts to us.
HSD190ME12-A02 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of HSD190ME12-A02 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of HSD190ME12-A02 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of HSD190ME12-A02 ?
A: We accept T/T , Paypal , western union .
Q: Can I pay my order of HSD190ME12-A02 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
HSD190ME12-A02 LCD Screen Other Policies :
In addition to our product-specific policies for the HSD190ME12-A02 LCD Screen, we'd like to outline a couple of other important policies to provide a comprehensive understanding of our service commitment:
1. Customs Duty and Import Tax:
- Please be aware that any customs duty or import tax incurred during the shipment process is the responsibility of the buyer. We do not assume liability for these charges, as they are determined by the customs regulations of the destination country.
- We recommend checking with your local customs office to understand potential duties or taxes associated with the import of the HSD190ME12-A02 LCD Screen.
2. Email Response Time:
- Our commitment to excellent customer service includes prompt communication. All emails sent to our customer support team will be answered within 24 hours of receipt.
- In the rare event that you do not receive a reply within this timeframe, please consider resending your email. We understand the importance of timely assistance, and we will make every effort to respond to your inquiry as soon as possible.
These policies aim to provide clarity and transparency in our business practices, ensuring that you have a positive and informed experience when engaging with our products and services. If you have any further questions or require additional information, please do not hesitate to reach out to our customer support team. Thank you for choosing our products, and we look forward to serving you with excellence.
