23.6 Inch M236H1-L08 Lcd Screen 480*6401920*1080 Liquid Crystal Display
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M236H1-L08 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M236H1-L08 | Diagonal Size: | 23.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 93PPI | Active Area: | 521.28(W)×293.22(H) Mm |
| Bezel Opening: | 525.22(W)×297.22(H) Mm | Outline Dim.: | 544.8(W)×320.5(H)×19.2(D) Mm |
| Treatment: | Antiglare (Haze 25%), Hard Coating (3H) | Weight: | 2.90/2.95Kgs (Typ./Max.) |
| Designed For: | Desktop Monitor | Interface Type: | LVDS (2 Ch, 8-bit) 30 Pins Connector |
| High Light: | LVDS liquid crystal display,M236H1-L08 lcd screen,23.6 inch liquid crystal display |
||
Product Description
23.6 inch 480*6401920*1080 liquid crystal display M236H1-L08 lcd screen
M236H1-L08 LCD Panel Product details :
| CMO LCD Screen SCREEN M236H1-L08 | |
|---|---|
| manufacturer | CMO |
| Model Name | M236H1-L08 |
| screen size | 23.6 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080 [FHD] 93PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 521.28(H)×293.22(V) mm |
| physical dimension | 544.8(H)×320.5(V) ×19.2(D) mm |
| Visual size | 525.22(H)×297.22(V) mm |
| surface treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 350 cd/m² (Typ.) |
| Contrast | 1100:1 (Typ.) (TM) |
| Best angle | 6 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| Responding time | 1.5/3.5 (Typ.)(Tr/Td) |
| Number of color | 16.7M 72% NTSC |
| Backlight type | CCFL [4 pcs] , 50K hours , W/O Driver |
| Weight | 2.90/2.95Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 23.6 inch 480*6401920*1080 liquid crystal display M236H1-L08 lcd screen | |
M236H1-L08 LCD Screen - Helpful Information for a Successful Purchase:
1. Size, Resolution, and Backlight Matching:
Size: Verify that the size of the M236H1-L08 LCD screen matches your specific requirements. Check the dimensions to ensure compatibility with your device.
Resolution: Match the resolution of the screen to your preferences and system specifications. Compatibility in resolution is vital for optimal display performance.
Backlight: Confirm that the backlight of the LCD screen aligns with your needs. Backlight technology can affect brightness and energy efficiency.
2. Uncertain? Contact Us for Expert Assistance:
If you find yourself uncertain about the compatibility of the M236H1-L08 LCD screen with your device, we encourage you to reach out to us.
Provide details such as your LCD brand, serial number, model, or the model number on the back of the screen. This information is instrumental in assisting you effectively.
3. Contacting Our Technicians:
Our experienced technicians are here to help you navigate the complexities of choosing the right LCD screen.
Feel free to contact us with your specific details, and our team will guide you through the selection process to ensure you purchase the correct screen for your needs.
4. Customer-Focused Support:
We understand the importance of customer satisfaction. Our commitment is to provide excellent support to guarantee that you receive the most suitable M236H1-L08 LCD screen for your application.
5. How to Reach Us:
For assistance, questions, or guidance, please contact our customer support team through the provided channels. We are ready to assist you in making an informed purchase decision.
M236H1-L08 LCD Panel Shipping and Package :
M236H1-L08 LCD Screen Shipping Information :
1. Order Processing Time:
The items you have ordered will be processed and prepared for shipment within 1 to 7 business days after your payment has been successfully completed.
Our commitment is to ensure that your order is handled promptly to minimize any delays in receiving your M236H1-L08 LCD screen.
2. Business Days Consideration:
Please be aware that the shipping time frame is based on business days, excluding weekends and public holidays. This allows us to maintain a precise schedule for order processing and dispatch.
3. Confirmation of Payment:
The initiation of the shipping process is contingent upon the successful completion of your payment. Once your payment is verified, we will proceed with preparing your order for shipment.
4. Shipment Notification:
Once your M236H1-L08 LCD screen is dispatched, you will receive a notification confirming the shipment. This notification may include tracking information, allowing you to monitor the progress of your delivery.
5. Delivery Time Estimate:
The actual delivery time will depend on your location and the shipping method chosen during the checkout process. Please refer to your tracking information for a more accurate estimate.
6. Shipping Partners:
We work with reliable shipping partners to ensure the secure and timely delivery of your orders. Our partnerships are established to provide you with a positive shipping experience.
M236H1-L08 LCD Screen - Contact Us for Order Inquiries:
1. Timely Contact:
If you haven't received your ordered goods within 45 days (excluding Christmas and New Year's Day), we encourage you to contact us promptly. Your satisfaction is our priority, and we are committed to addressing any concerns you may have.
2. Contact Information:
For assistance with order inquiries, please reach out to us through the contact information provided on our website or in your order confirmation. We are here to assist you and ensure that your concerns are addressed in a timely manner.
3. Exceptional Circumstances:
Please note that the 45-day timeframe is excluding Christmas and New Year's Day due to potential disruptions during these holiday periods. If you have not received your goods within a reasonable time during these exceptions, please contact us for further assistance.
4. Reshipment or Full Refund:
In the event that you have not received your goods as expected, we will promptly assess the situation. Depending on the circumstances, we are prepared to either resend your order or issue a full refund without any excuse. Your satisfaction is our commitment.
5. Our Customer Support Team:
Our dedicated customer support team is ready to assist you throughout this process. Feel free to contact us with your order details, and we will work diligently to resolve any issues and ensure your satisfaction.
M236H1-L08 LCD Panel FAQ :
Q: Do you accept sample orders of M236H1-L08 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of M236H1-L08 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of M236H1-L08 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of M236H1-L08 ?
A: Of course!sample order is welcome !
