M236h1-L07 Lcd Screen Display Original 23.6 Inch 30 pins Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M236H1-L07 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M236H1-L07 | Diagonal Size: | 23.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 93PPI | Active Area: | 521.28(W)×293.22(H) Mm |
| Bezel Opening: | 525.22(W)×297.22(H) Mm | Outline Size: | 544.8(W)×320.5(H) Mm |
| Response Time: | 0.7/2.3 (Typ.)(Tr+Td) | Weight: | 2.47/2.52Kgs (Typ./Max.) |
| Application: | Desktop Monitor | Signal Interface: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
| High Light: | M236h1-L07 Lcd Screen Display,Lcd Screen Display 23.6 Inch,30pins Connector Lcd Display |
||
Product Description
M236H1-L07 23.6 inch LCD SCREEN DISPLAY ORIGINAL
M236H1-L07 LCD Panel Product details :
| CMO LCD SCREEN M236H1-L07 | |
|---|---|
| Brand | CMO |
| Model | M236H1-L07 |
| Diagonal Size | 23.6 inch |
| Type | a-Si TFT-LCD , LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 93PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 521.28(H)×293.22(V) mm |
| Outline Dim. | 544.8(H)×320.5(V) mm |
| Bezel Area | 525.22(H)×297.22(V) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Operating Mode | TN, Normally White, Transmissive |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Response Time | 0.7/2.3 (Typ.)(Tr+Td) |
| Support Color | 16.7M 72% NTSC |
| Light Source | CCFL [2 pcs] , 50K hours , W/O Driver |
| Weight | 2.47/2.52Kgs (Typ./Max.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | No touch |
| Interface Type | LVDS (2 ch, 8-bit) 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| M236H1-L07 23.6 inch LCD SCREEN DISPLAY ORIGINAL | |
M236H1-L07 LCD Screen Note :
Large Inventory:
We maintain a substantial inventory of the M236H1-L07 LCD Screen. If you require a larger quantity, please feel free to contact us directly. We are here to accommodate your needs.
Urgent Requirements:
If you have an urgent requirement, we recommend selecting Express shipping options such as Fedex or DHL. This ensures quicker delivery, typically within 2-6 working days. The associated cost for this service is $28.88 after packaging for 1KG.
Shipping Time and Cost Variability:
It's important to note that shipping time and cost may vary based on factors such as item size, weight, and the destination country. Different countries may have different shipping costs and timelines.
Please keep the following considerations in mind:
Item size influences shipping costs.
Different weights may result in varying shipping expenses.
Shipping to different countries incurs different costs.
For specific details related to shipping costs and timelines, please contact us directly. We are committed to providing you with accurate and personalized information based on your requirements.
M236H1-L07 LCD Panel Shipping and Package :
M236H1-L07 LCD Screen Shipment Information :
Order Processing Time:
We aim to provide quick service. Usually, your goods will be prepared and shipped within 1 working day after your order is placed. This ensures a timely dispatch of the M236H1-L07 LCD Screen.
Condition Check Upon Receipt:
It is important to check the condition of your item upon receipt. Please inspect the M236H1-L07 LCD Screen to ensure it is in good condition. If there are any concerns or issues, please contact us promptly.
Delivery Time:
We offer two shipping options:
Via Express: Generally, you can expect delivery within 7-10 working days. This expedited option is ideal for those who require a faster delivery.
Via Air Mail: Generally, the delivery time is within 30-50 working days. This option is a more economical choice but may take longer.
Please choose the shipping method that best suits your preferences and timeline.
M236H1-L07 LCD Screen Return Policy:
Notification Requirement:
All returns must be informed before initiating the return process. The buyer is required to notify the seller of the intention to return items within 7 days after receiving the package.
Timeframe for Notification:
The buyer needs to notify the seller within 7 days after receiving the package. Requests for returns communicated beyond this timeframe may be subject to refusal.
Exchange for Buyer's Mistake:
In cases where the buyer ordered the wrong part, exchanges are possible. However, the buyer is responsible for covering the 2-ways shipping fee associated with the exchange.
Original Packaging and Condition:
Returned items must have all original packaging and should be in good condition. This ensures that the returned product is suitable for resale.
Non-Refundable Charges:
Return postage and insurance charges are non-refundable, whether the return is for a refund or a new shipment. Additionally, shipping fees incurred during the initial purchase are non-refundable.
M236H1-L07 LCD Panel FAQ :
Q: Can I pay my goods M236H1-L07 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of M236H1-L07 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders for M236H1-L07 ?
A: Of course!sample order is welcome !
Q: How to make payment for M236H1-L07 ?
A: We accept T/T , Paypal , western union .
