21.6 inch M216H1-L02 LCD Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M216H1-L02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M216H1-L02 | Diagonal Size: | 21.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 477.504(W)×268.596(H) Mm |
| Bezel Opening: | 481.5(W)×272.6(H) Mm | Outline Dim.: | 499.5(W)×292.6(H)×13.5(D) Mm |
| Treatment: | Antiglare (Haze 25%), Hard Coating (3H) | Weight: | 1.98/2.03Kgs (Typ./Max.) |
| Designed For: | Desktop Monitor | Interface Type: | LVDS (2 Ch, 8-bit) 30 Pins Connector |
Product Description
21.6 inch M216H1-L02 LCD Display Screen
M216H1-L02 LCD Panel Product details :
| CMO LCD SCREEN M216H1-L02 | |
|---|---|
| manufacturer | CMO |
| Model Name | M216H1-L02 |
| screen size | 21.6 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 477.504(W)×268.596(H) mm |
| physical dimension | 499.5(W)×292.6(H) mm |
| Visual size | 481.5(W)×272.6(H) mm |
| surface treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| Responding time | 1.3/3.7 (Typ.)(Tr/Td) |
| Number of color | 16.7M |
| Backlight type | 2 pcs CCFL , 50K hours , Without Driver |
| Weight | 1.98/2.03Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| 21.6 inch M216H1-L02 LCD Display Screen | |
M216H1-L02 LCD Display - Our Offerings:
1. 24/7 Customer Support:
Our dedicated customer support team is available around the clock to assist you. Whether you have inquiries, concerns, or require guidance, we are here to provide prompt and reliable support.
2. Competitive Chinese Pricing:
We aim to provide our customers with competitive pricing, leveraging our connections in China to offer you the best possible value for the M216H1-L02 LCD Display.
3. Streamlined Buying and Payment Process:
We understand the importance of a smooth purchasing experience. Our streamlined buying and payment process is designed to be efficient and user-friendly, ensuring a hassle-free transaction.
4. Global Delivery Services:
We take pride in our ability to deliver goods to customers worldwide with speed and precision. Whether you are located locally or internationally, our global delivery services are designed to meet your needs.
5. Commitment to Quality:
Ensuring the excellent quality of our products is a top priority. The M216H1-L02 LCD Display undergoes rigorous testing and quality control measures to meet the highest standards.
6. Sourcing Assistance:
In addition to providing LCD displays, we offer assistance in helping you find other products and manufacturers in China. Our network and expertise can streamline your sourcing process, saving you time and effort.
M216H1-L02 LCD Panel Shipping and Package :
M216H1-L02 LCD Display Shipment Information:
1. Worldwide Shipping:
We offer worldwide shipping to cater to our global customer base. Regardless of your location, you can benefit from our shipping services for the M216H1-L02 LCD Display.
2. DHL Shipping Method:
By default, we use DHL for shipping to all customers. DHL is known for its reliability and efficiency, providing delivery within 3-7 days. However, please note that in some countries, duty fees may apply, depending on the recipient's country policy.
Option for Low-Fee Courier (HK Post):
If you prefer a shipping method with lower fees and no custom fees, we can arrange for shipment via Hong Kong Post. Please be aware that the delivery time for this option is longer, usually taking 15-20 days to arrive.
3. Import Fees and Responsibilities:
It's important to note that we are not responsible for any import fees, remote area charges, taxes, or other customs-related fees. These charges are determined by the customs regulations of the recipient's country and are the responsibility of the customer. We recommend checking with local customs authorities to understand the potential fees associated with the importation of the M216H1-L02 LCD Display.
M216H1-L02 LCD Display Warranty & Return Policy:
1. One-Year Warranty:
A comprehensive one-year warranty is provided for new M216H1-L02 LCD Displays. This warranty covers any potential manufacturing defects or issues that may arise during normal use. If you encounter any concerns with the item, please notify us within the one-year warranty period.
2. Seven-Day Notification Period:
If you find yourself disappointed with the M216H1-L02 LCD Display, please inform us within 7 days of the delivery date. Timely communication enables us to address your concerns promptly and work towards a satisfactory resolution.
3. Return Conditions:
For a refund or exchange, items must be returned in their original condition. This includes the original packaging and all accessories. Returning the item in its original state helps facilitate the refund or exchange process.
4. Shipping Costs:
The shipping cost associated with the return is the responsibility of the customer. We understand the potential frustrations, and we encourage you to contact us before initiating the return process. Our customer support team is here to assist you and guide you through the necessary steps.
Important Note:
Man-made destruction is not covered under the warranty. Any damage caused by intentional or negligent actions is not eligible for warranty claims.
M216H1-L02 LCD Panel FAQ :
Q: How long is the warranty of M216H1-L02 ?
A: 90 days warranty .
Q: How can I trace my order of CMO M216H1-L02 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my goods M216H1-L02 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods M216H1-L02 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
