M215H1-L03 LCD screen display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M215H1-L03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M215H1-L03 | Diagonal Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 476.64(W)×268.11(H) Mm |
| Bezel Opening: | 479.8(W)×271.3(H) Mm | Outline Size: | 495.6(H)×292.2(V) ×16.85(D) Mm |
| Response Time: | 1.3/3.7 (Typ.)(Tr/Td) | Weight: | 2.59/2.64Kgs (Typ./Max.) |
| Designed For: | Desktop Monitor | Signal Interface: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
Product Description
M215H1-L03 LCD screen display panel
M215H1-L03 LCD Panel Product details :
| CMO LCD SCREEN M215H1-L03 | |
|---|---|
| manufacturer | CMO |
| Model Name | M215H1-L03 |
| screen size | 21.5 inch |
| Screen type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 476.64(W)×268.11(H) mm |
| physical dimension | 495.6(W)×292.2(H) ×16.85(D) mm |
| Visual size | 479.8(W)×271.3(H) mm |
| surface treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| Responding time | 1.3/3.7 (Typ.)(Tr/Td) |
| Number of color | 16.7M 74% NTSC |
| Backlight type | 4 pcs CCFL , 50K hours , Without Driver |
| Weight | 2.59/2.64Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| M215H1-L03 LCD screen display panel | |
M215H1-L03 LCD Screen Payment Guidelines:
To facilitate a smooth and secure payment process for your M215H1-L03 LCD screen, kindly adhere to the following instructions:
1. Accepted Payment Methods:
You can make payment using the available payment methods specified during the checkout process. Ensure that you choose from the provided options.
Payment must be completed within 3 days from the time of placing your order to avoid any delays in processing.
2. Refund Policy for Order Cancellation:
In the event of order cancellation, refunds will be processed promptly.
Refund agreements or mediations will be initiated instantly upon order cancellation.
Please note that it may take approximately 7-10 working days for the refunded amount to reflect in your account. The exact duration can vary based on your financial institution's processing time.
Important Considerations:
Ensure that you complete the payment within the stipulated 3-day period to avoid any issues with order processing.
If you need to cancel your order, be aware that the refund process will commence promptly, and the timeline for the refund to reach your account may vary.
Secure and Efficient Transactions:
Your payment security is a priority for us. The payment methods provided are secure, and we aim to make your transaction experience reliable and efficient.
M215H1-L03 LCD Screen Important Information:
To ensure a smooth and accurate ordering process for your M215H1-L03 LCD screen, please take note of the following:
1. Remove Old Screen Before Ordering:
Prior to placing your order, we recommend removing your old screen. This step allows for a thorough assessment of the existing model and ensures that you order the correct replacement. This proactive approach helps avoid compatibility issues and ensures a seamless installation process.
2. Provide LCD Model and Computer Details:
For accurate order processing, kindly provide the model details of both your LCD screen and your computer. This information is crucial in confirming compatibility. Before making a purchase, take a moment to share these details with us to ensure you receive the right product.
3. Compatibility Assurance:
While the exact model in the title may not always be sent, be assured that the compatible model will be dispatched. All products sent are guaranteed to be 100% compatible. If you require a specific model, we recommend reaching out to us before making your purchase to confirm availability.
4. Check Separation Capability of Your LCD Screen:
Confirm whether your LCD screen can be separated from the front cover plate of your computer. If separation is possible, you can opt to purchase a single LCD screen. In cases where separation is not feasible, you will need to acquire an LCD screen assembly with the front cover. Avoid any confusion by determining your specific needs before placing the order.
5. LCD Screen or Assembly:
To prevent ordering the wrong product, confirm whether you require a single LCD screen or a complete assembly with the front cover. This clarity is essential to ensure that the replacement component meets your specific requirements.
M215H1-L03 LCD Panel Shipping and Package :
M215H1-L03 LCD Screen Delivery Time Information:
We aim to provide you with transparency regarding the delivery process for your M215H1-L03 LCD screen. Please take note of the following details:
1. Order Processing Time:
Orders are typically processed within 3 days after receipt. During this time, we ensure that your order is prepared and ready for shipment.
2. Shipping Time Estimates:
The total shipping time is influenced by the efficiency of your local post office and customs. In general, the estimated shipping time to most countries is approximately 15-20 days. However, please note that this is an estimate, and actual delivery times may vary based on local factors.
3. Expedited Shipping Options:
If you require a more expedited delivery, we offer the option to choose DHL or EMS. Opting for these express shipping services can significantly reduce the delivery time, with packages typically arriving within 7-10 days. This is a suitable choice for those in urgent need of their orders.
Important Considerations:
Customs procedures may impact the overall delivery time, and these are beyond our control.
The estimated shipping times provided are general guidelines and may vary based on your specific location.
Urgent Delivery Options:
For urgent orders, we recommend selecting DHL or EMS during the checkout process to ensure a faster and more reliable delivery.
M215H1-L03 LCD Panel FAQ :
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: What's the different between original touch panel and compatible touch screen ?
A : Don't worry it . The compatible touch panel has the same function as original one .
Q: How long will I receive my goods of M215H1-L03 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for TIANMA Mobile Display M215H1-L03 ?
A: We accept T/T , Paypal , western union .
