Original 1920*1080 30 pin 21.5 inch TFT LCD Panel M215H1-L02
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M215H1-L02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M215H1-L02 | Diagonal Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 476.64(W)×268.11(H) Mm |
| Bezel Opening: | 479.8(W)×271.3(H) Mm | Outline Size: | 495.6(H)×292.2(V) ×16.85(D) Mm |
| Lamp Type: | CCFL [2 Pcs] , 50K Hours , W/O Driver | Weight: | 2.58/2.68Kgs (Typ./Max.) |
| Designed For: | Desktop Monitor | Signal Interface: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
Product Description
Original 1920*1080 30 pin 21.5 inch TFT LCD Panel M215H1-L02
M215H1-L02 LCD Panel Product details :
| CMO LCD SCREEN M215H1-L02 | |
|---|---|
| manufacturer | CMO |
| Model Name | M215H1-L02 |
| screen size | 21.5 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 476.64(W)×268.11(H) mm |
| physical dimension | 495.6(W)×292.2(H) ×16.85(D) mm |
| Visual size | 479.8(W)×271.3(H) mm |
| surface treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| Responding time | 1.3/3.7 (Typ.)(Tr/Td) |
| Number of color | 16.7M 72% NTSC |
| Backlight type | 2 pcs CCFL , 50K hours , Without Driver |
| Weight | 2.58/2.63Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Original 1920*1080 30 pin 21.5 inch TFT LCD Panel M215H1-L02 | |
