M190A1-L0G 19.0 inch 1440*900 lcd screen panel module
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M190A1-L0G |
| Document: | M190A1-L0G.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M190A1-L0G | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1440(RGB)×900, WXGA+ 89PPI | Active Area: | 408.24(W)×255.15(H) Mm |
| Bezel Opening: | 412.24(W)×259.15(H) Mm | Outline Size: | 428(W)×278(H) ×17(D) Mm |
| Surface: | Antiglare (Haze 25%), Hard Coating (3H) | Panel Weight: | 2.05/2.10Kgs (Typ./Max.) |
| Application: | Desktop Monitor | Signal Interface: | LVDS (2 Ch, 8-bit) , 30 Pins Connector |
Product Description
M190A1-L0G 19.0 inch 1440*900 lcd screen panel module
M190A1-L0G LCD Panel Product details :
| CMO LCD SCREEN M190A1-L0G | |
|---|---|
| Manufacturer | CMO |
| Model Name | M190A1-L0G |
| Screen size | 19.0 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1440(RGB)×900, WXGA+, 89PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 408.24(W)×255.15(H) mm |
| Outline Size | 428(W)×278(H) ×17(D) mm |
| Visual size | 412.24(W)×259.15(H) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| Responding time | 1.5/3.5 (Typ.)(Tr/Td) |
| Number of color | 16.7M 72% NTSC |
| Backlight type | 2 pcs CCFL , 40K hours , Without Driver |
| Weight | 2.05/2.10Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| M190A1-L0G 19.0 inch 1440*900 lcd screen panel module | |
M190A1-L0G LCD Screen Description:
Product Overview:
Model: M190A1-L0G LCD Screen
Type: a-Si TFT-LCD, LCM
Resolution: 1440(RGB)×900, WXGA+ 89PPI
Size: 19.0"
Compatibility: Desktop Monitor
M190A1-L0G LCD Panel Shipping and Package :
M190A1-L0G LCD Screen Shipping Method :
Express Shipping Options:
To ensure a swift and secure delivery, we ship the M190A1-L0G LCD screen using reliable express services. The available shipping options include:
DHL
FedEx
EMS
Chinese Post Express
Shipping Details:
Fast and Reliable:
Your M190A1-L0G LCD screen will be shipped using DHL, FedEx, EMS, or Chinese Post Express for fast and reliable delivery to your location.
Delivery Timeframe:
Expect your order to be delivered promptly, with delivery times varying depending on your location and the selected shipping method.
International Shipping:
Global Reach:
We provide international shipping, ensuring that customers worldwide can enjoy the benefits of the M190A1-L0G LCD screen.
Order Processing:
Efficient Processing:
Once your order is confirmed, we will process it efficiently to ensure that your M190A1-L0G LCD screen is dispatched at the earliest convenience.
Tracking Information:
Stay Informed:
As soon as your order is shipped, you will receive tracking information. This allows you to monitor the real-time progress of your shipment.
M190A1-L0G LCD Screen Return & Replace :
1. Notification of Non-Artificial Damage:
Timeframe for Notification:
If the M190A1-L0G LCD screen you received exhibits non-artificial damage, kindly notify us within 3 days of receiving the product. Timely notification allows us to address your concerns promptly.
2. Return Guidelines:
Original Package Requirement:
To facilitate a smooth return and replacement process, products should be returned in their original package. The original packaging is designed to provide optimal protection during transit and ensures the safe return of the item.
Condition of the Product:
Whenever possible, please return the product in good condition. This includes ensuring that the LCD screen is securely packaged and free from additional damage.
3. Return Authorization Process:
Contact Us Before Return:
Prior authorization is required for all returns. Please contact our customer support team before initiating the return process. We will guide you through the necessary steps and provide you with a return authorization.
Return Instructions:
Upon receiving authorization, we will provide you with detailed instructions on how to return the M190A1-L0G LCD screen. This will include information on where to send the product and any other relevant details.
4. Replacement Process:
Swift Replacement Procedure:
Once the returned product is received and inspected, we will initiate the replacement process promptly. Our goal is to ensure that you receive a fully functional M190A1-L0G LCD screen as soon as possible.
M190A1-L0G LCD Panel FAQ :
Q: Do you accept sample orders of M190A1-L0G ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of M190A1-L0G ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods M190A1-L0G ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of M190A1-L0G via credit card ?
A: Yes!you can use your credit card through your Paypal account.
