18.5 inch LCD Display Module LCD Panel Screen M185B1-L07
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | M185B1-L07 |
| Document: | M185B1-L07.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M185B1-L07 | Diagonal Size: | 18.5" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA 84PPI | Active Area: | 409.8(W)×230.4(H) Mm |
| Bezel Opening: | 413.4(W)×234.0(H) Mm | Outline Dim.: | 430.37(W)×254.6(H) ×11(D) Mm |
| Response Time: | 1.5/3.5 (Typ.)(Tr/Td) | Lamp Type: | 2 Pcs CCFL , 50K Hours , Without Driver |
| Application: | Desktop Monitor | Interface Type: | LVDS (1 Ch, 8-bit) , 30 Pins Connector |
Product Description
18.5 inch LCD Display Module LCD Panel Screen M185B1-L07
M185B1-L07 LCD Panel Product details :
| CMO LCD SCREEN M185B1-L07 | |
|---|---|
| Manufacturer | CMO |
| Model Name | M185B1-L07 |
| Screen size | 18.5 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768 (WXGA) 84PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 409.8 × 230.4 (H×V) |
| Outline Size | 430.37 × 254.6 × 11 (H×V×D) |
| Visual size | 413.4 × 234.0 (H×V) |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 200 cd/m² (Typ.) |
| Contrast | 700:1 (Typ.) (TM) |
| Best angle | 6 o'clock |
| Display Mode | TN, Normally White, Transmissive |
| Viewing angle | 45/45/20/45 (Typ.)(CR≥10) |
| Responding time | 1.5/3.5 (Typ.)(Tr/Td) ms |
| Number of color | 16.7M 72% NTSC |
| Backlight type | 2 pcs CCFL , 50K hours , No Driver |
| Weight | 1.43/1.48Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Signal system | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 18.5 inch LCD Display Module LCD Panel Screen M185B1-L07 | |
M185B1-L07 LCD Panel Payment and Tax Information:
1. Preferred and Secure Payment Method - Alipay:
We recommend using Alipay as your preferred payment method for a safe and secure transaction process. Alipay provides a reliable and trusted platform for processing payments, ensuring the security of your financial information.
2. Import Duties, Taxes, and Charges for International Shipments:
For products being shipped outside of China, please be aware that your order may be subject to import duties, taxes, and other charges imposed by the customs authorities in your destination country. These additional fees are not covered by the listed product price or shipping charges and are the sole responsibility of the recipient.
3. Understanding Additional Fees:
Import duties, taxes, and charges can vary based on your country's customs regulations. It's advisable to check with your local customs office to understand the specific fees that may apply to your order. Please note that these fees are not controlled or influenced by the product price or our shipping charges.
4. Recipient's Responsibility:
The recipient of the order is responsible for complying with their country's customs requirements and for paying any additional fees imposed by the customs authorities. We recommend researching and understanding your country's customs policies to ensure a smooth delivery process.
5. Transparent Communication:
To facilitate transparency in the purchasing process, we want our customers to be well-informed about potential additional charges associated with international shipments. We encourage you to contact our customer support if you have any questions or concerns regarding customs duties or taxes.
We value your understanding and cooperation in adhering to the necessary regulations for international shipments. Our commitment is to provide you with a clear and transparent purchasing experience, ensuring that you receive your M185B1-L07 LCD Panel without any unforeseen challenges.
M185B1-L07 LCD Panel Shipping and Package :
M185B1-L07 LCD Panel Shipping Information:
1. Swift Dispatch within 1-3 Working Days:
Your order is our priority. We commit to shipping the M185B1-L07 LCD Panel within 1-3 working days upon the receipt of payment. This prompt dispatch ensures that you receive your order in a timely manner.
2. Trusted Shipping Partners - FedEx, DHL, UPS, etc.:
We have partnered with reputable shipping carriers such as FedEx, DHL, UPS, and others to ensure reliable and efficient delivery of your M185B1-L07 LCD Panel. These carriers are known for their global reach and commitment to timely and secure deliveries.
3. Leave a Telephone Number for On-Time Delivery:
To enhance the efficiency of the delivery process, we kindly request that you provide a valid telephone number during the checkout process. This contact information allows the shipping carrier to communicate with you directly, ensuring on-time delivery and providing you with any necessary updates regarding your shipment.
4. Order Tracking for Your Convenience:
Once your order has been dispatched, we will provide you with a tracking number. This number enables you to monitor the real-time status and location of your shipment. With this information, you can anticipate the arrival of your M185B1-L07 LCD Panel and plan accordingly.
5. International Shipping Considerations:
If your order is being shipped internationally, please be aware of potential customs and import regulations in your country. Any applicable duties or taxes are the responsibility of the recipient and may vary depending on your location.
6. Customer Support for Any Inquiries:
Should you have any questions or concerns regarding the shipping process, our customer support team is available to assist you. We are committed to providing you with a seamless and transparent shipping experience.
M185B1-L07 LCD Panel Replacement Policy:
1. 30-Day Replacement or Exchange Window:
We understand that circumstances may arise where a replacement or exchange is necessary. Therefore, we offer a 30-day window for customers to initiate a replacement or exchange request. This provides you with a reasonable timeframe to assess the product and request a replacement if needed.
2. Maintain Original Condition:
To facilitate a smooth replacement process, it's essential for the buyer to keep the goods in the same condition as they were offered by us. This includes preserving the original packaging, accessories, and ensuring the product is free from any damage caused by factors not covered by the warranty.
3. Resending Goods in Case of Damage or Malfunction:
In the unfortunate event that the received goods are broken or do not function as intended, we are committed to resolving the issue promptly. We will resend the replacement goods to the buyer in a timely manner. Our goal is to minimize any inconvenience caused by defective or damaged products.
4. How to Initiate a Replacement or Exchange:
If you encounter any issues with the M185B1-L07 LCD Panel within the 30-day window, please contact our customer support team. They will guide you through the replacement process, including providing instructions on returning the product and facilitating the dispatch of a replacement.
5. Customer Satisfaction is Our Priority:
We prioritize customer satisfaction, and our replacement policy is designed to provide you with a hassle-free experience. We aim to address any issues promptly and ensure that you receive a fully functional and satisfactory product.
6. Warranty Information:
It's important to note that the replacement policy operates within the context of the product's warranty. Please refer to the warranty terms and conditions for additional information on coverage and duration.
M185B1-L07 LCD Panel FAQ :
Q: Do you accept sample orders of M185B1-L07 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of M185B1-L07 vai credit card ?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of M185B1-L07 ?
A: The order will be shipped within 2-3 working days after received your payment.
