HannStar HSD050IDW1-A00 5 Inch LCD Panel RGB 800*480 WVGA 188PPI
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD050IDW1-A00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD050IDW1-A00 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 188PPI | Active Area: | 108(W)×64.8(H) Mm |
| Bezel Opening: | 110.6(W)×67.4(H) Mm | Outline Dim.: | 118.5(W)×77.55(H) ×3.7(D) Mm |
| Surface: | Antiglare, Hard Coating (3H) | Viewing Angle: | 75/75/60/70 (Typ.)(CR≥10) |
| Weight: | 66.0g (Typ.) | Application: | Automotive Display / Portable Navigation / MID UMPC / MP3 PMP / Gaming |
| High Light: | HSD050IDW1-A00 LCD panel,Antiglare 5 Inch LCD Panel,WVGA 5 Inch LCD Panel |
||
Product Description
HannStar HSD050IDW1-A00 LCD panel 5.0 inch 800(RGB)*480 LCD display
HSD050IDW1-A00 Product details :
| HannStar LCD Screen HSD050IDW1-A00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD050IDW1-A00 |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×480, WVGA 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 108(W)×64.8(H) mm |
| Bezel Opening | 110.6(W)×67.4(H) mm |
| Outline Size | 118.5(W)×77.55(H) ×3.7(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 2/6 (Typ.)(Tr/Td) |
| Display Colors | 16.2M |
| Lamp Type | 7S2P WLED , 10K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Weight | 66.0g (Typ.) |
| Application | Automotive Display / Portable Navigation / MID UMPC / MP3 PMP / Gaming |
| Signal Interface | TTL (1 ch, 8-bit) , 40 pins FPC |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| HannStar HSD050IDW1-A00 LCD panel 5.0 inch 800(RGB)*480 LCD display | |
