AT050TN30 LCD Screen Display 5.0 inch RGB 480×272 WQVGA 109PPI
Product Details:
| Place of Origin: | China |
| Brand Name: | Chimei Innolux |
| Model Number: | AT050TN30 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | AT050TN30 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 480(RGB)×272, WQVGA 109PPI | Active Area: | 110.88(W)×62.832(H) Mm |
| Outline Dim.: | 117.7(H)×72.8(V) ×1.43(D) Mm | Treatment: | Antiglare |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Response Time: | 10/15 (Typ.)(Tr/Td) |
| Weight: | 25.0g | Designed For: | Portable Navigation / MP3 PMP |
| High Light: | WQVGA LCD Screen Display,AT050TN30 LCD Screen Display,AT050TN30 |
||
Product Description
5.0 inch 480*272 Resolution AT050TN30 LCD Screen Display
AT050TN30 Product details :
| Chimei Innolux LCD SCREEN AT050TN30 | |
|---|---|
| Manufacturer | Chimei Innolux |
| Model P/N | AT050TN30 |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, CELL , FOG |
| Resolution | 480(RGB)×272, WQVGA 109PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 110.88(W)×62.832(H) mm |
| Outline Dim. | 117.7(H)×72.8(V) ×1.43(D) mm |
| Treatment | Antiglare |
| Luminance | 0 cd/m² |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| 0.50+0.50 mm | 0.50+0.50 mm |
| Transmittance | 4.66% (Typ.)(with Polarizer) |
| Support Color | 16.7M 50% NTSC |
| Light Source | No B/L |
| Weight | 25.0g |
| Designed For | Portable Navigation / MP3 PMP |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| 5.0 inch 480*272 Resolution AT050TN30 LCD Screen Display | |
AT050TN30 Shipping:
1, We offer international shipping services through Alibaba Standard Shipping, ensuring reliable and efficient delivery of your goods.
2, Our shipping process begins promptly upon receiving your order. Within 3 working days, we carefully prepare and package your items for shipment.
3, With our efficient shipping methods, you can expect to receive your goods within a reasonable timeframe. Generally, deliveries are made within 10-20 calendar days from the date of dispatch.
4, To ensure smooth delivery, it is crucial that you provide accurate shipping information during the ordering process. Please double-check and confirm your address, postal code, phone number, and contact person details.
5, If you need to ship your order to a different address than the one provided, kindly inform us in advance. You can do so by leaving a message in the transaction or by contacting our customer service team.
AT050TN30 Reminder:
Please note that our prices do not include any customs taxes or fees that may be applicable in the destination country. The payment of customs taxes or fees, if any, will be your responsibility when the goods undergo customs clearance in the destination country. The specific customs regulations and laws vary from country to country.
We take pride in offering a wide range of high-quality products in our store. We kindly invite you to add our store to your store list, so you can stay updated with our latest offerings and promotions.
If you have any specific needs or requirements, please don't hesitate to contact us. Our dedicated customer support team will make every effort to assist you and ensure a satisfactory shopping experience.
AT050TN30 Shipping and Package :
AT050TN30 FAQ:
Q: Do you accept sample orders of AT050TN30 ?
A: Of course!sample order is welcome !
Q: Can You declare my order of AT050TN30 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of AT050TN30 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of AT050TN30 ?
A: Of course!If you make a large order, we will give you a discount.
AT050TN30 Contact Us:
If you encounter any issues or have any questions, please feel free to contact us via Whatsapp message. We strive to provide prompt assistance and will reply to your message within 1 business day, excluding public holidays.
Our work hours are from Monday to Friday. Please keep this in mind when expecting a response from us.
In case you do not receive a response within 1-2 business days, we recommend checking your email or My Messages. Occasionally, certain email providers may have aggressive spam filters that could potentially block our response. Please ensure that our messages are not being filtered out as spam.
