CHIMEI INNOLUX LCD Screen Display R196U2-L03 For Medical LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Chimei Innolux |
| Model Number: | R196U2-L03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | R196U2-L03 | Diagonal Size: | 19.6" |
|---|---|---|---|
| Resolution: | 1600(LCR)×1200, UXGA 102PPI | Active Area: | 398.4(W)×298.8(H) Mm |
| Outline Size: | 427(W)×322.4(H) ×38.3(D) Mm | Bezel Opening: | 402.4(W)×302.8(H) Mm |
| Brightness: | 700 Cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) (TM) |
| Weight: | 1.94/1.99Kgs (Typ./Max.) | Designed For: | Medical Imaging |
| High Light: | R196U2-L03 Medical LCD Panel,Antiglare Medical LCD Panel,R196U2-L03 LCD Screen Display |
||
Product Description
CHIMEI INNOLUX LCD Screen Display R196U2-L03 for Medical LCD Panel
R196U2-L03 Product details :
| Chimei Innolux LCD Screen R196U2-L03 | |
|---|---|
| Brand | Chimei Innolux |
| Model P/N | R196U2-L03 |
| Diagonal Size | 19.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1600(RGB)×1200, UXGA 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 398.4(W)×298.8(H) mm |
| Bezel Opening | 402.4(W)×302.8(H) mm |
| Outline Dim. | 427(H)×322.4(V)×38.3(D) mm |
| Treatment | Antiglare |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 15/10 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥20) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | CCFL [16 pcs] , 50K hours , With Inverter |
| Weight | 1.94/1.99Kgs (Typ./Max.) |
| Designed For | Medical Imaging |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 40 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 55 °C ; Storage Temperature: -20 ~ 60 °C |
| CHIMEI INNOLUX LCD Screen Display R196U2-L03 for Medical LCD Panel | |
R196U2-L03 Shipping and Package :
R196U2-L03 Shipping Information:
To ensure a smooth and efficient shipping process, please take note of the following details:
Consignee Information: When placing an order, please provide the full name of the consignee (the person who will receive the shipment) and a detailed shipping address. The complete and accurate address information will help ensure that the product is delivered to the correct location.
Quality Assurance: Prior to shipping, all items undergo a rigorous testing process using real equipment. This ensures that the products are in 100% working condition before they are shipped to the customers.
Shipment Timing: Once payment is received, all items will be shipped within 72 business hours. Please note that this excludes Saturdays, Sundays, and statutory holidays. The seller strives to process and ship orders promptly to minimize any delays in delivery.
Shipping Service Reliability: The seller is committed to providing the most reliable and affordable shipping service possible. However, it's important to note that international delivery can be influenced by factors such as the courier company's efficiency and the customs and duties processes in the destination country.
Non-delivery Assistance: If you do not receive your item within the expected timeframe, please contact the seller immediately for further assistance. They will be able to provide support and help track the shipment to ensure its timely delivery.
It is recommended to maintain regular communication with the seller throughout the shipping process to address any concerns or seek assistance as needed. This will help ensure a smooth and satisfactory delivery experience.
Please keep in mind that while the seller strives to provide a reliable shipping service, there may be circumstances beyond their control that could impact the delivery timeline. Stay in touch with the seller for updates and assistance regarding your shipment.
R196U2-L03 Taxes & import duties:
Responsibility for Taxes and Duties: The buyer is responsible for paying all taxes and import duties associated with the shipment. This means that any applicable customs fees, taxes, or duties imposed by the destination country are not included in the price of the product and must be paid separately by the buyer.
Import Regulations: It's important to note that each country has its own import regulations and policies regarding taxes and duties. These regulations may vary depending on the type of product, its value, and the destination country's customs policies. It is advisable for the buyer to research and understand the specific import regulations and associated costs applicable in their country before making a purchase.
Customs Clearance: When the product arrives in the destination country, it will go through customs clearance procedures. During this process, customs officials may assess and charge applicable taxes and import duties based on the declared value of the product. The buyer is responsible for providing any necessary documentation and paying the required fees to clear the product through customs.
It's important to consult with local customs authorities or seek professional advice to understand the specific taxes, import duties, and customs clearance procedures applicable in your country. They will be able to provide accurate and up-to-date information based on your specific circumstances.
Please note that the seller or the product company may not be able to provide precise information about the taxes and import duties as these are determined by the destination country's customs authorities.
Ensuring compliance with import regulations and fulfilling any tax or duty obligations is the responsibility of the buyer.
R196U2-L03 FAQ:
Q: Do you accept sample orders of R196U2-L03 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of R196U2-L03 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of R196U2-L03 ?
A: We accept T/T , Paypal , western union .
Q: Can You declare my order of R196U2-L03 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
