Original R196U2-L01 Medical LCD Panel Screen 1600(LCR)×1200 UXGA 102PPI
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | R196U2-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | R196U2-L01 | Diagonal Size: | 19.6" |
|---|---|---|---|
| Resolution: | 1600(LCR)×1200, UXGA 102PPI | Active Area: | 398.4(W)×298.8(H) Mm |
| Bezel Opening: | 402.4(W)×302.8(H) Mm | Outline (mm): | 427×322.4×38.3 (H×V×D) |
| Luminance: | 600 Cd/m² (Typ.) | Contrast Ratio: | 600 : 1 (Typ.) (TM) |
| Mass: | 1.97Kgs (Max.) | Used For: | Medical Imaging |
| High Light: | R196U2-L01 Medical LCD Panel,102PPI Medical LCD Panel,Medical Imaging LCD Screen Display |
||
Product Description
Original R196U2-L01 LCD Screen Display Panel for Medical Imaging
R196U2-L01 Product details :
| CMO LCD Screen R196U2-L01 | |
|---|---|
| Brand | CMO |
| Model P/N | R196U2-L01 |
| Diagonal Size | 19.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1600(RGB)×1200, UXGA 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 398.4(W)×298.8(H) mm |
| Bezel Opening | 402.4(W)×302.8(H) mm |
| Outline (mm) | 427×322.4×38.3 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 25/25 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | 16 pcs CCFL , 50K hours , With Inverter |
| Mass | 1.97Kgs (Max.) |
| Used for | Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , Connector 40 pins |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Original R196U2-L01 LCD Screen Display Panel for Medical Imaging | |
R196U2-L01 Introduction:
The R196U2-L01 LCD is a high-quality display panel specifically designed for medical imaging applications. With its impressive specifications and reliable performance, it offers a clear and accurate visual experience for professionals in the medical field. This article provides an overview of the key features and specifications of the R196U2-L01 LCD.
R196U2-L01 Impressive Display Specifications:
Diagonal Size: The R196U2-L01 LCD boasts a large diagonal size of 19.6 inches, providing ample screen real estate for viewing medical images and diagnostic data.
Resolution: The display offers a resolution of 1600 (RGB) × 1200 pixels, providing a crisp and detailed image quality. With a pixel density of 102PPI, the R196U2-L01 ensures clear and precise visuals.
Active Area: The active area of the screen measures 398.4mm in width and 298.8mm in height, offering a spacious viewing area for medical professionals to analyze and interpret medical images.
Bezel Opening: The bezel opening measures 402.4mm in width and 302.8mm in height, allowing for a sleek and aesthetically pleasing design while maximizing the screen space for an immersive viewing experience.
Outline Dimensions: The R196U2-L01 LCD has compact outline dimensions of 427mm (width) × 322.4mm (height) × 38.3mm (depth), making it suitable for various medical imaging setups.
Good View at: The display panel ensures a good view from various angles, providing symmetry and optimal visibility for medical professionals in different viewing positions.
Lightweight Design: With a maximum mass of 1.97 kilograms, the R196U2-L01 LCD is lightweight and easy to handle, making it convenient for installation and transportation.
R196U2-L01 Designed for Medical Imaging:
The R196U2-L01 LCD is specifically tailored for medical imaging applications, catering to the needs of radiologists, doctors, and healthcare professionals. Its high resolution, accurate color reproduction, and wide viewing angles enable precise analysis of medical images, including X-rays, CT scans, and MRIs. The display's exceptional clarity and detail assist in accurate diagnosis, treatment planning, and monitoring patient progress.
R196U2-L01 Signal Type and Connectivity:
The R196U2-L01 LCD utilizes LVDS (Low-Voltage Differential Signaling) as the signal type, offering a reliable and high-speed data transmission. With a 2-channel, 8-bit LVDS configuration, it ensures a smooth and efficient display performance. The display panel features a 40-pin connector, providing a secure and stable connection to compatible devices.
R196U2-L01 Conclusion:
The R196U2-L01 LCD is a remarkable display panel that excels in medical imaging applications. Its large screen size, high resolution, wide viewing angles, and accurate color reproduction make it an ideal choice for healthcare professionals. With its lightweight design and convenient connectivity options, it offers both practicality and reliability. Whether it's for radiology, diagnostics, or surgical applications, the R196U2-L01 LCD delivers an exceptional visual experience, contributing to enhanced medical imaging and patient care.
R196U2-L01 Shipping and Package :
Guarantee and Return Policy for the R196U2-L01 LCD:
Warranty Period: The R196U2-L01 LCD comes with a one-week warranty period, which covers any manufacturing defects or malfunctions that may occur. However, please note that the warranty does not cover errors caused by user mishandling or incorrect installation.
Refund Guarantee: Our product company offers a 30-day refund guarantee, allowing customers to return the product within 30 days of purchase if they are not satisfied. However, it is important to note that this refund guarantee is subject to certain conditions.
Buyer's Responsibility for Return Shipping Fee: In the case of a return, the buyer is responsible for covering the return shipping fee. This ensures that the return process remains cost-effective for both the buyer and the seller.
Return License Requirement: To initiate a return, it is necessary to request a return license from our product company. This process helps ensure that all returns are properly tracked and managed.
R196U2-L01 FAQ:
Q: How long is the warranty of R196U2-L01 ?
A: 90days warranty .
Q: Can I pay my goods R196U2-L01 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods R196U2-L01 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
