R190ECE-L01 LCD Monitors 19.0 Inch LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Chimei Innolux |
| Model Number: | R190ECE-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | R190ECE-L01 | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1280(RGB)×1024, SXGA 86PPI | Active Area: | 376.32(W)×301.056(H) Mm |
| Bezel Opening: | 380.3(W)×305.0(H) Mm | Outline(mm): | 396(H)×324(V) ×14(D) Mm |
| Luminance: | 330 Cd/m² (Typ.) | Response Time: | 15/15 (Typ.)(Tr/Td) |
| Weight: | 1.70±0.10Kgs | Designed For: | Medical Imaging |
| High Light: | R190ECE-L01 Medical LCD Display,TFT Medical LCD Monitor,SXGA 86PPI Medical LCD Screen |
||
Product Description
R190ECE-L01 LCD Monitors 19.0 inch LCD Screen Display
R190ECE-L01 Product details :
| Innolux LCD Screen R190ECE-L01 | |
|---|---|
| Brand | Innolux |
| Model P/N | R190ECE-L01 |
| Diagonal Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 376.32(W)×301.056(H) mm |
| Bezel Opening | 380.3(W)×305.0(H) mm |
| Outline(mm) | 396(H)×324(V) ×14(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 330 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 15/15 (Typ.)(Tr/Td) |
| Good View at | Symmetry |
| Operating Mode | AAS, Normally Black, Transmissive |
| Support Color | 16.7M |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 1.70±0.10Kgs |
| Designed For | Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 55 °C |
| R190ECE-L01 LCD Monitors Screen Display | |
R190ECE-L01 Description:
Welcome to YONGS digital Store. Our store specializes in selling all kinds of screens and driver boards.
* We will strictly test them before delivery to ensure that you can receive the perfect machine.
* We will deliver the goods within 3 working days after your payment. The buyer is responsible for customs duties.
* Please check whether the screen is complete before receiving the goods. If damaged, please take photos and refuse to receive the goods.
* Before testing or installing the LCD screen, please turn off the power/unplug the battery of the device, otherwise it will not work.
* International transportation usually takes 10-45 working days. If you haven't received the package for a long time, please contact us.
We provide various LCD screens, touch screens, inverters and other accessories. Please contact
R190ECE-L01 Shipping and Package :
R190ECE-L01 Shippment:
The panel will be 100% check and test before shippment.
We will handle your order within 3-5 business day after got your order(Weekends And Holidays Excluded).
It usually takes 15-60 business days for international shipping.If the parcel don't arrive you for a long time,pls kindly contact with us.
We also can offer Expedited International Shipping(FedEx,UPS or DHL) with extra fee if you need the item urgently.
Buyer is responsible for customs duty fee.
R190ECE-L01 Return:
1.Our Return Policy does not extended to any products that are physically damaged or that are not under normal operating conditions as a result of misuse or improper installation on the buyer/user's part.
2.This product comes with 60-Day Money Back Guarantee.
3.For all returned products, please contact us for the returning address.
4.We stand behind every product we sell. If you're not pleased with your purchase, we'll be happy to make an exchange or refund.
R190ECE-L01 FAQ:
Q: If I place order now,when will you ship the goods of R190ECE-L01 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of R190ECE-L01 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of R190ECE-L01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
