1024*768 lcd panel LQ150X1LX96 TFT 15.0 inch Industrial LCD Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | SHARP |
| Model Number: | LQ150X1LX96 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ150X1LX96 | Diagonal Size: | 15.0" |
|---|---|---|---|
| Resolution: | 1024(RGB)×768[XGA] 85PPI | Active Area: | 304.128 × 228.096 Mm (H×V) |
| Outline(mm): | 326.5 × 253.5 × 10.1 Mm (H×V×D) | Luminance: | 500(Typ.)(cd/m²) |
| Contrast Ratio: | 1500 : 1 (Min.) (TM) | Viewing Angle: | 85/85/85/85 (Typ.) (CR≥10) |
| Number Of Color: | 262K/16.2M , 70% NTSC | Used For: | Industrial |
Product Description
1024*768 lcd panel LQ150X1LX96 TFT 15.0 inch Industrial LCD Display Screen
LQ150X1LX96 Product details :
| SHARP LCD SCREEN LQ150X1LX96 | |
| Brand | SHARP |
| Model Name | LQ150X1LX96 |
| Diagonal Size | 15.0 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1024(RGB)×768[XGA] 85PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 304.128 × 228.096 mm (H×V) |
| Bezel Opening | 307.4 × 231.3 mm (H×V) |
| Outline Size | 326.5 × 253.5 × 10.1 mm (H×V×D) |
| Surface | Antiglare (Haze 3%), Hard coating (3H) |
| Brightness | 500 (Typ.) |
| Contrast Ratio | 1500:1 (Typ.) |
| Viewing angle | 85/85/85/85 (Typ.) (CR≥10) |
| Display Mode | ASV, Normally Black, Transmissive |
| Number of color | 262K/16.2M , 70% NTSC |
| Reaction time | 35 (Typ.)(Tr+Td) |
| Backlight type | WLED , 70K hours, with LED driver |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Application | Industrial |
| Panel Weight | 950g (Max.) |
| Signal Interface | LVDS (1 ch, 6/8-bit) , terminal, 20 pins |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -25 ~ 70 °C Operating temperature: -20 ~ 70 °C |
| 1024*768 lcd panel LQ150X1LX96 TFT 15.0 inch Industrial LCD Display Screen | |
LQ150X1LX96 Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
LQ150X1LX96 Package included:
1pc lcd panel
LQ150X1LX96 Shippment
The panel will be 100% check and test before shippment.
We will handle your order within 3-5 business day after got your order(Weekends And Holidays Excluded).
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
We also can offer Expedited International Shipping(FedEx,UPS or DHL) with extra fee if you need the item urgently.
Buyer is responsible for customs duty fee.
LQ150X1LX96 Return& Refund:
Please read the item description and check the pictures carefully before bidding.
Refund or Return is available if the item arrived broken,not as described or does not do what it's supposed to.
LQ150X1LX96 Note:
Dear Brazil customers ,
Due to your country customs rule,When you place an order , Please write receiver full name and correct CPF , And we have to declare real price on customs invoice , thanks for your understand!
We have more than 12 years experience on lcd displays filed . Our LCD Display will be tested ok before shipping . So it is very safe for you to do lcd display business with us .
Because Our company have many LCD models, we can't uploaded real product pictures for each model, but we will send you the correct products. If you are worried about product problems, you can contact us before placing an order.
LQ150X1LX96 FAQ:
Q: How can I trace my order of LQ150X1LX96 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can you give me a discount if I need a large quantity of LQ150X1LX96 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of LQ150X1LX96 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long will I receive my goods LQ150X1LX96?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
LQ150X1LX96 Shipping and Package :
